ABB CI615 3BHT300024R1 bus coupler

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Overview

The ABB CI615 3BHT300024R1 Bus Coupler is a critical module for ABB PLC systems, connecting the main controller (e.g., CPU module) with I/O expansion modules or remote fieldbus devices for efficient data transmission and system expansion.
It provides high-speed, low-latency communication and reliable power distribution, ensuring stable and accurate signal transmission between the PLC system and external modules. Suitable for industrial automation, robotic systems, process control, and energy management.

Technical Specifications

Model: CI615
Part Number: 3BHT300024R1
Module Type: Bus Coupler
Supported Systems: ABB AC500 / AC800M PLC series
I/O Expansion Support: Up to 16 I/O modules (system-dependent)
Communication Interface: Backplane bus and external fieldbus interfaces
Power Supply: 24 V DC (±10%)
Power Consumption: approx. 6 W
Response Time: <2 ms
Operating Temperature: 0°C to +55°C
Storage Temperature: -25°C to +70°C
Relative Humidity: 5%–95%, non-condensing
Protection Rating: IP20
Mounting: DIN rail or cabinet backplane
Dimensions: approx. 130 × 80 × 35 mm
Weight: approx. 0.42 kg
Certifications: CE / UL / RoHS

Features & Advantages

1. Efficient Bus Coupling – Enables fast communication between the main controller and I/O expansion modules or remote devices.

2. Modular Design – Supports hot-swapping for easy system upgrades and maintenance.

3. Stable Power Distribution – Provides reliable 24 V DC to I/O expansion modules.

4. High-Speed Response – Less than 2 ms response time suitable for high-speed control systems.

5. Industrial-Grade Durability – Designed for long-term operation in harsh environments.

6. Full ABB PLC Compatibility – Seamlessly integrates with AC500 / AC800M series modules.

Applications

• I/O expansion and management for ABB PLC systems

• Automated production line control and data acquisition

• Industrial robot system communication and integration

• Process automation and monitoring systems

• Energy management and factory automation systems

• Motor drive and servo control interfaces

Precautions

1. Disconnect power before installation or maintenance.

2. Align the module properly when inserting to avoid backplane damage.

3. Use shielded cables for I/O modules and fieldbus connections to reduce EMI.

4. Do not exceed the maximum allowed expansion modules in the system.

5. Regularly check connectors and screws to ensure module stability.

6. Use genuine ABB modules to ensure compatibility and system stability.
