ABB CBM-01 3HNA009409-001 Top-mounted circuit board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Description

The ABB CBM-01 3HNA009409-001 Top-mounted Circuit Board is a key control component for low-voltage circuit breakers and distribution equipment. Mounted on top of the breaker, it manages signal processing, status indication, control logic execution, and protection functions. The CBM-01 board features a compact structure and stable performance, ensuring long-term reliable operation in industrial environments.

2. Technical Specifications

• Model: CBM-01 3HNA009409-001

• Type: Top-mounted Circuit Board

• Applicable Equipment: ABB low-voltage circuit breakers and distribution modules

• Operating Voltage: 24–48 V DC (logic control supply)

• Input/Output Interfaces: Control signal inputs, status signal outputs

• Mounting: Top-mounted, directly connected to circuit breaker

• Operating Temperature: -25 ℃ to +60 ℃

• Storage Temperature: -40 ℃ to +85 ℃

• Protection Class: IP20

• Standards Compliance: CE, UL

3. Advantages and Key Features

• Compact and reliable design for space-saving and perfect integration with the breaker.

• High-performance signal processing for precise control logic execution and fast status feedback.

• Durable and stable in wide temperature range, vibration-resistant, and dust-proof for industrial use.

• Easy installation and maintenance with modular design for quick replacement, minimizing downtime.

• Strong compatibility with ABB low-voltage breakers and distribution modules, ensuring system consistency.

4. Typical Applications

• ABB low-voltage circuit breaker control systems

• Distribution boards and industrial distribution systems

• Motor protection and control circuits

• Automation control systems

• Industrial equipment status monitoring and signal feedback

5. Precautions

• Disconnect power before installation or maintenance to prevent electric shock or damage.

• Ensure logic control supply voltage is within the specified range.

• Avoid exposure to high humidity, corrosive, or high-vibration environments.

• Regularly check the circuit board and wiring terminals for reliable operation.

• Do not disassemble or modify the board to maintain performance and safety.
