ABB CA5-40E Auxiliary Contact Block

1. Key Parameters

• Product Model: CA5-40E
• Product Series: ABB CA Series Auxiliary Contact Blocks (Contactor/Starter Accessory, Modular Design)
• Core Function: Adds auxiliary NO (Normally Open) and NC (Normally Closed) contacts to ABB contactors (e.g., AF, AX series) and motor starters; transmits control signals for status monitoring, interlocking, or alarm circuits; ensures mechanical and electrical synchronization with the primary contactor’s operation
• Electrical & Contact Specifications:

  Parameter	Details	Performance Metrics
  Contact Configuration	- Contact Type: 4 NO (Normally Open) - Number of Poles: 4 independent poles - Contact Rating: 10A at 250V AC (resistive load); 2A at 250V AC (inductive load) - Breaking Capacity: 0.3A at 250V AC (for inductive loads, cosφ=0.4)	4 NO contacts support multiple parallel control circuits (e.g., status LED, PLC input, alarm relay) without additional blocks
  Electrical Performance	- Insulation Resistance: ≥100MΩ (at 1000V DC) - Dielectric Strength: 2.5kV AC (between contacts and ground, 1 minute) - Contact Resistance: ≤50mΩ (initial) - Electrical Life: 100,000 operations (at rated load)	High insulation resistance prevents leakage current; low contact resistance ensures minimal voltage drop for reliable signal transmission
  Mechanical Synchronization	- Actuation: Mechanically linked to contactor/starter (no separate power required) - Response Time: <10ms (contacts switch in sync with primary contactor) - Mechanical Life: 1,000,000 operations (no-load)	Instantaneous synchronization with primary contactor ensures accurate status signaling; long mechanical life reduces replacement frequency

• Mechanical Specifications:
  • Dimensions: 18mm (W) × 85mm (H) × 55mm (D) (modular, single-width)
  • Mounting Type: Snap-on to ABB contactors (AF09~AF80, AX09~AX80 series) or 35mm DIN rail (with adapter)
  • Housing Material: Polyamide 6.6 (UL 94 V0, flame-retardant, impact-resistant)
  • Weight: Approximately 55g
  • IP Rating: IP20 (suitable for control cabinet installation)
• Environmental Ratings:
  • Operating Temperature Range: -25℃~+70℃ (-13℉~158℉)
  • Storage Temperature Range: -40℃~+85℃ (-40℉~185℉)
  • Humidity Tolerance: 5%~95% RH (non-condensing, 40℃)
  • Vibration Resistance: 10~500Hz, 1g acceleration (IEC 60068-2-6)
  • Shock Resistance: 30g (11ms half-sine, IEC 60068-2-27)
• Compliance Standards: CE, RoHS, IEC 60947-5-1 (auxiliary contact blocks), UL 508, CSA C22.2 No.14, ABB Contactor Compatibility Standard

2. Key Features

• 4 NO Contact Configuration: Provides four independent normally open contacts—supports simultaneous control of multiple circuits (e.g., status indication, PLC input, interlock) in a single compact block, reducing cabinet space by 50% vs. using multiple single-contact blocks.
• Snap-On Modular Design: Easily mounts to compatible ABB contactors (AF/AX series) without tools—eliminates complex wiring between contactor and auxiliary block, reducing installation time by 40% and minimizing wiring errors.
• Mechanical Synchronization: Contacts switch in perfect sync with the primary contactor (<10ms response time)—ensures accurate real-time status signaling (e.g., "contactor ON" LED activates instantly), avoiding delays that could cause control logic errors.
• High Mechanical & Electrical Life: 1,000,000 mechanical operations and 100,000 electrical operations—matches the lifespan of ABB contactors, ensuring long-term system reliability and reducing maintenance costs.
• Wide Compatibility: Works with ABB AF09~AF80 and AX09~AX80 contactors; optional DIN rail adapter enables standalone mounting—flexible for both contactor-integrated and independent control circuit applications.
• Flame-Retardant Housing: Polyamide 6.6 material with UL 94 V0 rating—prevents flame spread in case of internal electrical faults, enhancing control cabinet safety in industrial environments.
• Global Electrical Compliance: Meets IEC, UL, and CSA standards—suitable for use in global industrial applications (e.g., Europe, North America, Asia) without regional modifications.

3. Application Fields

• Contactor Control Circuit Expansion: Primary use with ABB contactors:
  • Motor Starter Status Monitoring: Adds NO contacts to AF series contactors in motor starters—transmits "motor ON" signals to PLC inputs or status LEDs, enabling operators to remotely verify motor operation in manufacturing lines or HVAC systems.
  • Interlocking Circuits: Creates interlocks between multiple contactors (e.g., in conveyor systems or pump banks)—prevents simultaneous activation of conflicting devices (e.g., forward/reverse motors), avoiding mechanical damage or process errors.
• Industrial Automation Signaling: Enhancing control logic:
  • PLC Input Signals: Provides NO contacts for connecting to PLC digital inputs—transmits contactor/starter status to automation systems (e.g., ABB AC800M), enabling centralized monitoring of equipment in smart factories.
  • Alarm & Shutdown Circuits: Triggers alarms or emergency shutdowns via NO contacts—e.g., in power distribution systems, a "contactor fault" signal can activate an audible alarm or isolate the circuit to prevent cascading failures.
• HVAC & Building Automation: Supporting climate control systems:
  • Compressor Status Tracking: Integrates with AX series contactors in HVAC compressors—NO contacts send "compressor running" signals to building management systems (BMS), optimizing energy use by coordinating with thermostat inputs.
  • Fan Motor Interlocks: Creates interlocks between supply and exhaust fan contactors in commercial buildings—ensures exhaust fans activate before supply fans, maintaining proper air pressure and indoor air quality.
• Power Distribution Systems: Ensuring electrical safety:
  • Circuit Breaker Auxiliary Signals: Works with contactors in low-voltage power distribution—NO contacts signal when a circuit is energized, enabling remote monitoring of power flow in data centers or industrial switchgear.
  • Capacitor Bank Control: Adds NO contacts to contactors controlling power factor correction (PFC) capacitor banks—transmits "capacitor connected" signals to PFC controllers, ensuring optimal power factor adjustment.

4. Precautions

• Contactor Compatibility (Critical): Use only with ABB AF09~AF80 and AX09~AX80 contactors—mounting to incompatible contactors (e.g., non-ABB models, smaller AF/AX series) causes mechanical misalignment, leading to contact failure or damage to both components. Verify compatibility via ABB’s product cross-reference tool.
• Installation & Wiring Safety:
  • Snap-On Alignment: Ensure the block is fully seated on the contactor’s mounting rail—partial installation causes intermittent contact actuation; listen for an audible "click" to confirm secure attachment.
  • Wire Size Limitation: Use 0.5~2.5mm² stranded or solid wires—exceeding 2.5mm² damages terminal clamps; strip insulation to 6mm (±1mm) to ensure proper contact and avoid short circuits.
  • Polarity & Circuit Loading: Do not exceed the contact’s rated current (10A AC resistive)—overloading causes contact welding or overheating; avoid connecting inductive loads >2A AC without derating (consult ABB’s load derating chart).
• Operation & Maintenance:
  • Contact Inspection: Check for contact wear or oxidation annually (for high-use applications)—signs include increased contact resistance (>100mΩ) or intermittent signal loss; replace the block if contacts are pitted or burned.
  • 定期检查: Perform semi-annual inspections for:
    • Loose wires (vibration may loosen terminals—retighten to specified torque)
    • Mechanical linkage damage (ensure contacts move freely when the contactor operates)
    • Housing cracks (replace immediately if damage allows dust/moisture ingress)
  • Cleaning Protocol: Clean terminals with a dry, lint-free cloth—avoid using compressed air or solvents; dust accumulation on contacts increases resistance and signal distortion.
• Environmental Limitations:
  • Temperature Extremes: Avoid operation below -25℃ (housing becomes brittle) or above +70℃ (contact resistance increases)—use cabinet heaters/coolers in extreme environments to maintain operating temperature range.
  • Humidity Exposure: Protect from condensing humidity (>95% RH)—install dehumidifiers in control cabinets in tropical or coastal regions; moisture causes terminal corrosion and electrical leakage.
• Replacement & Spare Parts:
  • Genuine ABB Components: Use only genuine CA5-40E blocks—non-genuine alternatives have inferior contact materials (e.g., brass vs. silver alloy) and shorter lifespans (100,000 vs. 1,000,000 mechanical operations). Verify authenticity via ABB’s serial number lookup tool.
  • Spare Inventory: Maintain 1 spare block per 20 installed units—critical for minimizing downtime in control circuits; store spares in static-free packaging at room temperature (15℃~25℃) to preserve contact integrity
•
•
