1. Product Description

The ABB CA5-22M Auxiliary Contact Block is a modular auxiliary contact device designed for motor control and distribution systems. It is used in conjunction with contactors or circuit breakers to provide signal feedback, interlocking, and control logic expansion. The module features a reliable mechanical structure and highly conductive contacts, ensuring long-term stable operation in industrial environments.

2. Technical Specifications

• Model: CA5-22M

• Type: Auxiliary Contact Block

• Contact Configuration: 2 NO + 2 NC

• Rated Current: 5 A

• Rated Voltage: AC 400 V / DC 220 V

• Contact Material: Silver alloy

• Mechanical Life: > 10,000,000 operations

• Electrical Life: > 100,000 operations (rated load)

• Mounting: Directly mounted on contactor or circuit breaker

• Operating Temperature: -25 ℃ to +60 ℃

• Storage Temperature: -40 ℃ to +85 ℃

• Protection Class: IP20

• Standards Compliance: IEC 60947-5-1, CE

3. Advantages and Key Features

• High-reliability contacts with silver alloy for stable conductivity and low contact resistance.

• Modular design allows direct mounting on contactors or circuit breakers for easy control expansion and feedback.

• Multi-function control with 2 NO + 2 NC contacts for diverse logic and interlock applications.

• Industrial-grade durability with wide temperature tolerance and long mechanical and electrical life.

• Easy installation with snap-on or screw mounting, saving time and effort.

4. Typical Applications

• Motor control circuits

• Contactor signal feedback and status indication

• Auxiliary logic control in distribution systems

• Automation control systems

• Industrial equipment interlocks and protection circuits

5. Precautions

• Disconnect power before installation or maintenance to prevent electric shock or equipment damage.

• Ensure contact voltage and current ratings match the control circuit to avoid overload.

• Avoid exposure to high humidity, corrosive, or high-vibration environments.

• Regularly check contact status and wiring terminals to ensure reliable operation.

• Do not disassemble or modify the module to maintain performance and safety.

The structure and details of the product：
