ABB BTDR-01C 3AUA0000094845 power board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Overview

The ABB BTDR-01C (3AUA0000094845) is a high-performance Power Supply Board designed for ABB industrial drives such as the ACS800 and ACS880 series. It supplies stable DC power to the control board, driver circuits, and auxiliary power modules. Built with industrial-grade components, the BTDR-01C ensures high reliability, strong EMC resistance, and comprehensive protection features, making it an essential component for the stable operation of ABB drive systems.

Technical Specifications

• Model: BTDR-01C

• Part Number: 3AUA0000094845

• Category: Power Board / Power Supply Module

• Compatible Drives: ABB ACS800 / ACS880 Series

• Input Voltage: 24 V DC (Control Power Input)

• Output Voltages: +5 V / +15 V / -15 V DC

• Max Output Power: 60 W

• Voltage Regulation: ±2%

• Protection Functions: Overvoltage, Undervoltage, Short-circuit, Overload

• Dielectric Strength: > 1500 V AC (input/output isolation)

• Cooling Method: Natural air cooling

• Connection Interface: Multi-pin connector to main control board

• Mounting: Screw-fixed or modular slot installation

• Operating Temperature: -10 ℃ to +70 ℃

• Storage Temperature: -40 ℃ to +85 ℃

• Humidity: < 95%, non-condensing

• Weight: approx. 0.45 kg

• Certifications: CE, UL, RoHS

Key Features & Advantages

1. High Reliability – Engineered for ABB drive systems, stable 24/7 operation.

2. Multi-Voltage Output – Provides multiple regulated DC voltages for control and logic circuits.

3. Comprehensive Protection – Built-in protection against overvoltage, overload, and short circuits.

4. Strong EMC Performance – Excellent resistance to industrial electrical noise.

5. Modular Design – Easy installation, maintenance, and replacement, minimizing downtime.

Applications

• ABB industrial drives (ACS800 / ACS880 series)

• Motor drive and servo control systems

• Industrial automation and process control

• Energy, mining, and heavy equipment systems

• Petrochemical, metallurgy, and manufacturing automation

Precautions

1. Ensure model compatibility before installation.

2. Always disconnect power and discharge capacitors before maintenance.

3. Avoid operation in high humidity or corrosive gas environments.

4. Check terminal connections regularly for secure contact.

5. Use only genuine ABB spare parts to maintain system safety and reliability.

The structure and details of the product：

Please make an inquiry for more models
