ABB BC6-30-10-01 Miniature Contactor

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB BC6-30-10-01 is a compact miniature AC contactor designed for controlling low-power motors and circuits. It is small, easy to install, and highly reliable, suitable for single-phase or three-phase loads, commonly used in industrial automation, lighting systems, and small machinery.

2. Technical Specifications

• Model: BC6-30-10-01

• Brand: ABB

• Type: Miniature AC Contactor

• Rated Coil Voltage: AC 230 V

• Rated Current: 6 A (AC-3, inductive load)

• Number of Poles: 3P (3 poles)

• Contact Configuration: 3 NO (normally open) contacts

• Mechanical Life: ~1,000,000 operations

• Electrical Life: ~100,000 operations (rated load)

• Operating Temperature: ‑25 °C to +55 °C

• Protection Rating: IP20

• Mounting: DIN rail or screw mounting

• Auxiliary Contacts: Optional external modules

• Load Types: Low-power motors, lighting, heaters, and control circuits

3. Key Advantages & Features

1. Compact Design – Space-saving, ideal for small control systems.

2. High Reliability – High-quality contacts ensure stable long-term operation.

3. Easy Installation & Maintenance – Supports DIN rail and screw mounting; easy to replace.

4. Versatile Use – Suitable for AC small motors, lighting, heaters, and general control loads.

5. Energy Efficient – Low coil power reduces energy consumption and heat.

6. Safety Protection – IP20 protection; can be paired with overload relays for enhanced safety.

4. Typical Applications

• Small industrial machinery and automation systems

• Single-phase or three-phase motor control

• Lighting switching and control

• Small heating or fan control devices

• Home appliances and distribution control systems

• Laboratory or test equipment control circuits

5. Installation & Usage Notes

1. Power Matching – Ensure coil voltage matches rated AC 230 V.

2. Wiring & Mounting – Correctly connect contacts and tighten screws to avoid poor contact.

3. Environmental Conditions – Avoid high humidity, dust, and corrosive environments; maintain ventilation.

4. Heat Management – Minimal heat generation, but avoid use in sealed high-temperature spaces.

5. Regular Inspection – Check contacts and coil condition periodically for reliable operation.
