ABB BC6-30-01 Three-pole contactor

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• Technical Specifications

  • Model: BC6-30-01 (also known as BC6-30-01-01 / BC6-30-01-P in different coil-voltage variants)

  • Contact Configuration: 3 main poles (3NO) + 1 auxiliary contact (1 NC)

  • Coil: typically 24 V DC (other coil-voltage versions may exist)

  • Insulation Voltage (Ui): up to 690 V AC (per IEC / UL/CSA 600 V rating)

  • Rated Operational Current (AC-1): 20 A at 220/240 V or 380/440 V (at 40 °C); at 690 V: 6 A

  • Motor Power Rating (AC-3, 3-phase motors): up to ~4 kW (at 400 V AC)

  • Mechanical Life: ~10,000,000 operating cycles

  • Dimensions: 52.5 mm (W) × 46.5 mm (D) × 57.5 mm (H)

  • Mounting: DIN-rail or panel/ wall mount; screw-terminal connections

  • Operating Temp. / Environment: –25 °C to +55 °C; suitable for typical industrial control cabinets

  • Protection Degree: IP20 (for enclosed electrical cabinets)

  Advantages & Features

  • Compact & space-efficient design: small footprint and light weight — ideal for cramped control cabinets or compact installations.

  • 3-pole with auxiliary contact: supports 3-phase main power switching plus auxiliary signal contact for control or monitoring.

  • Wide voltage/current compatibility: can handle up to 690 V AC and up to 20 A (AC-1), with capability to switch small to medium 3-phase motors (~4 kW).

  • Low coil power consumption & quiet operation: coil is suitable for direct control (e.g. by PLC outputs), with minimal noise and hum.

  • High reliability & long service life: mechanical durability up to 10 million cycles — suitable for frequent switching or long-term operation.

  • Flexible mounting options: supports DIN-rail or panel/wall mounting, convenient for various control-cabinet designs.

  Typical Application Areas

  • Motor control and start/stop switching: for 3-phase motors (pumps, fans, compressors, small machine tools) — especially motors up to ~4 kW.

  • Industrial automation systems: as main switching element in control cabinets, automation panels for motors, heaters, fans, etc.

  • Commercial / residential building electrics: for HVAC, lighting, building automation, where compact size and reliability are beneficial.

  • General resistive or mixed load switching: for heaters, resistive loads, lighting groups, etc.

  • Control panel / distribution integration: well-suited for integration in PLC-based control cabinets or distribution systems because of auxiliary contact and mounting style.

  Usage Notes / Recommendations



  • Ensure load voltage and current are within the rated specifications (≤ 690 V AC, ≤ 20 A for AC-1; motor load ≤ 4 kW for AC-3).

  • Use correct coil-voltage version (e.g. 24 V DC) matching your control system or PLC output.

  • Mount securely on DIN-rail or panel; ensure terminals are properly tightened and wiring is well organized.

  • Use within controlled environment (enclosed cabinet, avoid dust, moisture, strong EMI) for longevity; consider proper shielding / enclosure if necessary.

  • For frequent switching or high-duty cycles, perform periodic inspections of contacts and mechanical parts to maintain reliable operation.

•

The structure and details of the product：
