ABB BB510 3BSE001693R2 bus backplane

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Overview

The ABB BB510 3BSE001693R2 Bus Backplane is a core component of ABB PLC and control systems, providing interconnections and power distribution for I/O modules, CPU modules, and other expansion modules.
It ensures reliable, high-speed, low-latency communication between modules and supports modular expansion for easy system upgrades and maintenance.

Technical Specifications

Model: BB510
Part Number: 3BSE001693R2
Module Type: Bus Backplane
Supported Systems: ABB AC500 / AC800M PLC
Module Slots: Up to 16 I/O modules (depending on system configuration)
Communication Interface: Backplane bus connectors
Power Distribution: 24 V DC to all modules
Max Supported Power: approx. 100 W (depends on module count)
Operating Temperature: 0°C to +55°C
Storage Temperature: -25°C to +70°C
Relative Humidity: 5%–95%, non-condensing
Protection Rating: IP20
Mounting: DIN rail or cabinet backplane
Dimensions: approx. 450 × 120 × 35 mm
Weight: approx. 1.8 kg
Certifications: CE / UL / RoHS

Features & Advantages

1. Reliable Data Communication – Ensures fast and stable signal transmission between modules.

2. Modular Design – Supports hot-swapping for easy expansion and maintenance.

3. Centralized Power Distribution – Provides stable 24 V DC to all I/O modules.

4. Industrial-Grade Durability – Vibration, dust, and electrostatic resistant for long-term operation.

5. High Compatibility – Seamlessly compatible with ABB AC500 / AC800M modules.

6. System Upgrade Friendly – Easily add or replace modules as needed.

Applications

• ABB PLC system control cabinets

• I/O expansion and management in automated production lines

• Industrial robot control system integration

• Process automation and energy management systems

• Water treatment, power, and chemical process control systems

Precautions

1. Disconnect power before installation or maintenance to prevent electric shock or module damage.

2. Align modules properly during insertion to avoid damaging backplane connectors.

3. Avoid operation in high humidity, dust, or strong EMI environments.

4. Do not exceed the maximum allowed module count on the backplane.

5. Regularly inspect connectors and fastening screws to ensure module stability.

6. Use genuine ABB modules to ensure compatibility and system reliability.
