ABB AX561 Analog Input/Output Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB AX561 Analog Input/Output Module is a high-performance module designed for industrial automation systems. It provides reliable analog signal acquisition and output control for voltage and current signals. AX561 seamlessly integrates with PLCs and distributed I/O systems to monitor and control field devices, making it ideal for expanding analog I/O functions in automation projects.

2. Technical Specifications

3. Key Features and Benefits

1. Multi-channel Analog I/O
   Provides 4 analog inputs and 2 analog outputs, supporting both voltage and current signals.

2. High Resolution and Accuracy
   Built-in 12-bit A/D and D/A converters deliver precise measurement and control.

3. Differential Input Design
   Differential input supports effective noise rejection and better signal quality.

4. Robust Industrial Design
   Compact and durable structure suitable for industrial environments with temperature variations and electrical noise.

5. Easy System Integration
   Compatible with PLC and distributed I/O systems, easy to install and expand analog I/O capabilities.

6. Real-time Status Indication
   LED indicators provide clear feedback on power and module status for easy diagnostics.

4. Typical Applications

ABB AX561 is widely used in:

• Process automation control systems

• PLC analog I/O extension

• Energy monitoring and power systems

• Machine signal acquisition and control

• Sensor data processing systems

• Field data acquisition and actuator control

• Industrial automation in manufacturing, chemical, energy, and transportation sectors

5. Precautions and Usage Recommendations

1. Power Supply Requirements
   Ensure 24V DC power supply is correct before powering the module.

2. Wiring Standards
   Follow proper wiring connection for inputs, outputs, and power terminals to avoid misconnection or shorts.

3. Differential Wiring Advice
   Use shielded twisted-pair cables for differential analog signals to minimize interference.

4. Temperature and Environment
   Avoid long-term exposure to moisture, high heat, or dusty environments to maintain reliable performance.

5. Range Configuration
   Configure appropriate signal types and measurement ranges in the PLC or control system to ensure accuracy.
