ABB AX12-30-10 contactor

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Description

The ABB AX12-30-10 is a high-performance AC contactor from ABB’s AX series, designed for motor control and power switching applications. It is known for its compact design, long service life, and reliable operation, making it ideal for frequent switching in control circuits, including motor starting, stopping, and reversing operations.

Technical Specifications

• Model: AX12-30-10

• Manufacturer: ABB

• Type: AC Contactor

• Rated Operational Current (AC-3, 400V): 12 A

• Rated Operational Voltage: 24V / 110V / 230V / 400V AC (depending on coil version)

• Rated Insulation Voltage (Ui): 690 V

• Rated Impulse Withstand Voltage (Uimp): 6 kV

• Rated Power (AC-3, 400V): 5.5 kW (three-phase motor)

• Main Contacts: 3 NO

• Auxiliary Contacts: 1 NO

• Coil Voltage: 24…500 V AC/DC (varies by model)

• Mechanical Life: ≥ 10 million operations

• Electrical Life: ≥ 1 million operations (AC-3 duty)

• Mounting Type: DIN rail or screw mounting

• Protection Degree: IP20

• Operating Temperature: -25°C to +55°C

• Weight: Approx. 0.4 kg

Features & Advantages

1. High-Performance Coil System: Low power consumption and quiet operation.

2. Modular Design: Easily combined with thermal overload relays, auxiliary contacts, and mechanical interlocks.

3. Long Service Life: High mechanical and electrical endurance.

4. Reliable and Safe: Excellent arc suppression and contact stability.

5. Wide Voltage Range: Multiple coil voltage options for flexible installation.

6. Easy Installation: Compact and modular design supports DIN rail mounting.

7. International Certification: Compliant with IEC, UL, and CSA standards.

Application Fields

• Motor starting and control circuits

• Distribution panels and control cabinets

• Industrial automation systems

• Lighting and heating control

• Pumps, fans, and compressors

• Elevators and conveyor systems

Precautions

1. Ensure coil voltage matches the control voltage before installation.

2. Tighten all terminals securely to prevent poor contact.

3. Avoid use in high humidity or dusty environments; use protective enclosures if needed.

4. Regularly inspect contact wear and coil temperature rise.

5. Match thermal overload relays according to rated current.

6. Always disconnect power before maintenance or replacement.

The structure and details of the product：
