ABB AX09-30-10-84 contactor

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB AX09-30-10-84 AC Contactor is a high-performance electrical switching device used in industrial and commercial control systems to switch motors and loads on and off. It is suitable for AC load control, offering high durability, reliable switching performance, and a modular design. The AX09-30-10-84 can be combined with thermal overload relays and auxiliary contact modules for a complete motor protection and control solution.

2. Technical Specifications

• Model: AX09-30-10-84

• Type: AC Contactor

• Rated Voltage: AC 220–690 V

• Rated Current: 9 A (AC-3 motor load)

• Poles: 3

• Coil Voltage: AC 230 V / DC 24 V optional

• Mechanical Life: ≥ 10,000,000 operations

• Electrical Life: ≥ 1,000,000 operations

• Mounting: DIN rail or screw mounting

• Auxiliary Contacts: Optional NO/NC modules

• Protection Rating: IP20

• Dimensions (W×H×D): ~45 × 65 × 60 mm

• Weight: ~0.25 kg

3. Advantages and Features

• High reliability and durability: Supports long-term frequent operation in industrial environments.

• Modular design: Can be combined with thermal relays and auxiliary contacts to meet diverse control requirements.

• Multiple coil voltages: AC or DC coil options for different control systems.

• Energy-efficient and safe: Optimized coil consumption and safety features reduce energy usage and risk of faults.

• Compact installation: Small footprint suitable for control panels and distribution cabinets.

4. Typical Applications

• Industrial motor control and starting

• Conveyor systems and pump drives

• HVAC systems and fan control

• Factory automation and production line control

• Commercial buildings and energy management systems

5. Installation & Usage Notes

• Ensure coil voltage and load current match before installation.

• Tighten all wiring terminals to prevent loose connections or overheating.

• Install in a dry, ventilated environment to prevent dust or liquid ingress.

• Regularly check contactor operation and auxiliary contacts to ensure reliable control.

• Avoid using above rated current or voltage to prevent damage.
