ABB AX 722F 3BDH000377R0001 analog input/output module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Description

The ABB AX 722F 3BDH000377R0001 Analog Input/Output Module is an industrial-grade module designed for data acquisition and control signal output in ABB automation systems.
It allows analog signals from field sensors (such as voltage, current, or temperature) to be input into the control system, while providing standard analog output signals to control actuators or drives.

The AX 722F module features high-precision components and industrial-grade design, offering reliable signal conversion and isolation to ensure system control accuracy and stability.

Technical Specifications

• Model: AX 722F

• Part Number: 3BDH000377R0001

• Manufacturer: ABB

• Type: Analog Input/Output Module

• Input Type: 0–10 V, 4–20 mA, Thermocouple, RTD

• Output Type: 0–10 V, 4–20 mA

• Channels: 8 Input / 8 Output (configurable)

• Accuracy: ±0.1% FS

• Resolution: 16-bit

• Response Time: ≤ 10 ms

• Operating Temperature: 0°C to +60°C

• Storage Temperature: -25°C to +70°C

• Supply Voltage: 24 V DC

• Protection Class: IP20

• Mounting Type: DIN rail or slot installation

• Weight: Approx. 0.5 kg

Features & Advantages

1. High-Precision Signal Handling: Ensures accurate signal acquisition and output.

2. Multi-Channel Support: Handles multiple analog signals simultaneously, improving system efficiency.

3. Industrial Reliability: EMI-resistant design suitable for complex industrial environments.

4. Signal Isolation: Input/output isolation prevents interference and electrical damage.

5. Fast Response: Short response time suitable for rapid control systems.

6. Flexible Configuration: Supports various input/output types configurable per application.

7. Easy Installation and Maintenance: DIN rail or slot-mounted, easy to replace or expand.

8. ABB System Compatibility: Seamless integration with PLC, DCS, and other automation control systems.

Application Fields

• Industrial automation production lines

• PLC/DCS system data acquisition and control

• Process control systems (chemical, pharmaceutical, food, petrochemical)

• HVAC systems and building automation

• Power system analog monitoring

• Water and wastewater treatment equipment control

• Robotics and mechatronic control systems

Precautions

1. Disconnect power before installation for safety.

2. Ensure input/output signal types match module configuration.

3. Keep installation environment well-ventilated, avoiding high temperature and dust.

4. Shield and ground signal wires to prevent interference.

5. Regularly inspect wiring and module status to ensure reliable operation.

6. Do not disassemble or modify the module to avoid performance degradation.

7. Investigate abnormal outputs or alarms promptly.

8. Avoid prolonged operation above specified temperature limits.
