                                                                                                                                                                                                                                                                          • ABB AI830 3BSE040662R2 Analog Input Module

                                                                                                                                                                                                                                                                            Product Overview

                                                                                                                                                                                                                                                                            The ABB AI830 (3BSE040662R2) Analog Input Module is an 8-channel RTD analog input module designed for the ABB S800 I/O system. It is mainly used for temperature measurement applications, receiving signals from resistance temperature detectors (RTD) such as Pt100, Cu10, Ni100, Ni120 and resistive sensors, then converting them into digital values for ABB control systems.

                                                                                                                                                                                                                                                                            The AI830 supports 3-wire RTD connection and provides high-accuracy temperature acquisition for process automation systems such as System 800xA.

                                                                                                                                                                                                                                                                            ---

                                                                                                                                                                                                                                                                            Specifications

                                                                                                                                                                                                                                                                            Parameter	Description
                                                                                                                                                                                                                                                                            Brand	ABB
                                                                                                                                                                                                                                                                            Model	AI830
                                                                                                                                                                                                                                                                            Part Number	3BSE040662R2
                                                                                                                                                                                                                                                                            Product Type	Analog Input Module
                                                                                                                                                                                                                                                                            Series	S800 I/O
                                                                                                                                                                                                                                                                            Input Type	RTD / Resistance Input
                                                                                                                                                                                                                                                                            Number of Channels	8 Channels
                                                                                                                                                                                                                                                                            Sensor Types	Pt100, Cu10, Ni100, Ni120, Resistive Potentiometer
                                                                                                                                                                                                                                                                            Connection Type	3-wire RTD
                                                                                                                                                                                                                                                                            Resolution	14 Bit
                                                                                                                                                                                                                                                                            Isolation	Group isolated from ground
                                                                                                                                                                                                                                                                            HART Support	No
                                                                                                                                                                                                                                                                            Redundancy	No
                                                                                                                                                                                                                                                                            Mounting System	ABB S800 I/O
                                                                                                                                                                                                                                                                            Compatible MTU	TU810V1, TU812V1, TU814V1, TU830V1, TU833
                                                                                                                                                                                                                                                                            Battery	No Battery



                                                                                                                                                                                                                                                                            ---

                                                                                                                                                                                                                                                                            Advantages & Features

                                                                                                                                                                                                                                                                            • 8-channel RTD temperature measurement capability
                                                                                                                                                                                                                                                                            • Supports multiple industrial temperature sensors
                                                                                                                                                                                                                                                                            • High-precision 14-bit signal conversion
                                                                                                                                                                                                                                                                            • Individual channel configuration
                                                                                                                                                                                                                                                                            • Supports open-circuit and short-circuit monitoring
                                                                                                                                                                                                                                                                            • Designed for ABB S800 I/O distributed control systems
                                                                                                                                                                                                                                                                            • Suitable for continuous industrial operation



                                                                                                                                                                                                                                                                            ---

                                                                                                                                                                                                                                                                            Applications

                                                                                                                                                                                                                                                                            • ABB System 800xA DCS Systems
                                                                                                                                                                                                                                                                            • Temperature Monitoring Systems
                                                                                                                                                                                                                                                                            • Power Generation Equipment
                                                                                                                                                                                                                                                                            • Chemical Processing Plants
                                                                                                                                                                                                                                                                            • Oil & Gas Automation
                                                                                                                                                                                                                                                                            • Furnace and Heating Control
                                                                                                                                                                                                                                                                            • Process Industry Instrumentation
                                                                                                                                                                                                                                                                            • Factory Automation

                                                                                                                                                                                                                                                                            ---

                                                                                                                                                                                                                                                                            Precautions

                                                                                                                                                                                                                                                                            • Confirm RTD sensor type before configuration.
                                                                                                                                                                                                                                                                            • Verify compatibility with ABB S800 I/O system.
                                                                                                                                                                                                                                                                            • Check correct MTU terminal unit.
                                                                                                                                                                                                                                                                            • Ensure proper 3-wire sensor wiring.
                                                                                                                                                                                                                                                                            • Disconnect power before replacement.
                                                                                                                                                                                                                                                                            • Use anti-static protection when handling the module.

The structure and details of the product：
