ABB AI625 analog input module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB AI625 Analog Input Module Technical Documentation

Product Description

The ABB AI625 is a 16-channel analog input module designed for PLC and industrial automation systems. It converts field sensor signals (e.g., temperature, pressure) into high-precision digital data via 12-bit resolution A/D conversion. Supporting RS-485 communication and MODBUS RTU protocol, it enables distributed data acquisition in harsh industrial environments (-25°C to +70°C) .

Detailed Technical Parameters

Key Features & Advantages

1. High-Speed Precision

   • 12-bit resolution and 2 μs conversion time ensure accurate real-time signal acquisition for dynamic control systems .

2. Multi-Module Scalability

   • RS-485 interface allows daisy-chaining multiple modules (address-coding support), expanding input capacity for large-scale systems .

3. Industrial Robustness

   • DIN rail design with wide temperature tolerance (-25°C to +70°C), suitable for vibration-prone environments like manufacturing plants .

4. Seamless Integration

   • Native MODBUS RTU compatibility enables direct connection to SCADA, PLCs (e.g., ABB AC500), and HMI software without additional converters .

5. Low Maintenance Design

   • Self-diagnostic circuits detect channel faults (e.g., open wire), reducing downtime in critical processes .

Application Fields

1. Process Automation

   • Temperature/pressure monitoring in chemical reactors, flow rate control in pipelines .

2. Energy Management

   • Grid voltage/current acquisition in substations, renewable energy system analytics .

3. Manufacturing Control

   • CNC machine tool feedback, robotic arm position sensing .

4. Building Management Systems (BMS)

   • HVAC load monitoring, chiller plant optimization .

5. Environmental Monitoring

   • Wastewater pH measurement, emission gas analysis in scrubbers .

Critical Precautions

1. Wiring & Grounding

   • Use shielded twisted-pair cables for analog signals; separate from power lines ≥20 cm to prevent EMI interference. Ensure single-point grounding in noisy environments .

2. Environmental Limits

   • Avoid installation near heat sources (>50°C) or conductive dust. Maintain humidity <95% non-condensing 1.

3. Configuration Rules

   • Set unique MODBUS addresses (1–247) for each module in multi-device networks; verify baud rate parity with host controller .

4. Voltage Protection

   • Add surge suppressors for field inputs exposed to lightning risks (e.g., outdoor sensors). Never exceed ±15 V input to avoid ADC damage .

5. Maintenance Protocol

   • Calibrate zero/span annually using precision voltage sources; inspect terminal blocks for corrosion quarterly.
