ABB AGDR-72CIGBT module

ABB AGDR-72C IGBT Module Product Information

Overview:

The ABB AGDR-72C IGBT module is a high-performance power semiconductor module designed for various industrial and commercial applications. It provides efficient switching performance and reliable current control, utilizing the latest Insulated Gate Bipolar Transistor (IGBT) technology to operate stably under high voltage and current conditions. The AGDR-72C IGBT module is widely used in frequency converters, motor drives, wind power generation, power electronics, and other applications, serving as a core component for efficient energy conversion and control.

Detailed Specifications:

• Model: AGDR-72C

• Module Type: IGBT (Insulated Gate Bipolar Transistor)

• Rated Voltage: 1200V

• Rated Current: 72A

• Switching Frequency: 20 kHz - 30 kHz (depending on application and load conditions)

• Thermal Resistance: 0.3°C/W

• Operating Temperature Range: -40°C to +125°C

• Max Junction Temperature: 150°C

• Packaging Type: Thin module (for effective heat dissipation design)

• Protection Features: Overcurrent protection, overtemperature protection, short circuit protection

• Cooling Method: Forced air cooling or liquid cooling

• Application Types: Power conversion, industrial drives, motor control, wind energy conversion, UPS systems, etc.

• Package Specifications: Standardized interfaces, easy integration with various control and power modules

• Reliability: High-reliability design for harsh environments

• Certifications: UL, CE, IEC 60747-9

Advantages and Features:

1. High Efficiency Switching
   The AGDR-72C IGBT module utilizes advanced IGBT technology, providing fast and efficient switching performance suitable for high-frequency operation, improving overall system efficiency and stability.

2. High Load Capacity
   The module can withstand a rated voltage of up to 1200V and a current of 72A, making it suitable for high-power and high-voltage applications and capable of handling heavy loads.

3. Low Thermal Resistance
   With a low thermal resistance design, the AGDR-72C ensures efficient heat dissipation, minimizing heat buildup and enhancing module cooling performance, which extends its service life.

4. Wide Operating Temperature Range
   The module supports a wide operating temperature range from -40°C to +125°C, ensuring stable operation even under extreme environmental conditions.

5. Protection Features
   The AGDR-72C IGBT module is equipped with multiple protection functions, including overcurrent, overtemperature, and short circuit protection, effectively preventing damage from electrical faults or environmental issues.

6. Ease of Integration
   The module features standardized packaging and interfaces, enabling easy integration with ABB inverters, power drives, and other systems, simplifying system integration.

7. High Reliability and Long Lifespan
   Utilizing advanced packaging technology and high-quality semiconductor materials, the AGDR-72C IGBT module offers high reliability, suitable for long-term continuous operation in industrial systems.

Applications:

1. Frequency Converters and Motor Drives
   The AGDR-72C IGBT module is widely used in frequency converters (VFDs) and motor drive systems to provide efficient power conversion and precise current control, ensuring smooth operation of motors.

2. Wind Power Generation
   In wind power systems, IGBT modules are used for power conversion and adjusting wind turbine output power, helping optimize wind energy efficiency and ensuring stable power transmission.

3. UPS (Uninterruptible Power Supply) Systems
   Used in UPS systems, the AGDR-72C IGBT module helps optimize power conversion processes, ensuring stable power supply, especially in critical applications such as data centers and hospitals.

4. Power Electronics Equipment
   In high-power power electronics equipment such as power transmission and substation equipment, the AGDR-72C provides efficient current control and voltage regulation to ensure stable system operation.

5. Electric Vehicle Charging Systems
   The module is also widely used in electric vehicle (EV) charging systems, providing efficient power control and conversion, helping improve charging efficiency and response times.

6. Power Drive Systems
   Suitable for various power drive systems, including industrial automation, robotics, etc., the AGDR-72C provides efficient power conversion, improving system precision and efficiency.
