ABB AGDR-71C IGBT Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Overview

The ABB AGDR-71C IGBT module is a high-performance power electronic component that integrates Insulated Gate Bipolar Transistors (IGBTs) and fast recovery diodes for efficient power conversion and switching under high voltage and current conditions.
It is widely used in industrial drives, inverters, motor control systems, UPS devices, and renewable energy converters. The AGDR-71C delivers high reliability, low power loss, superior thermal management, and robust electrical isolation — making it an essential component in ABB’s advanced power and drive systems.

Technical Specifications (Typical)

• Model: AGDR-71C

• Type: IGBT Power Module

• Rated Voltage: 1200 V

• Rated Current: 400 A

• IGBT Technology: NPT / Trench Field Stop

• Collector-Emitter Saturation Voltage (V_CE(sat)): approx. 2.1 V @ 400 A

• Switching Frequency: up to 20 kHz

• Junction Temperature Range (T_vj): –40°C to +150°C

• Isolation Voltage: 2500 Vrms (1 min)

• Power Loss: 10–15% lower than comparable standard modules

• Package Type: Modular housing, easy to mount and cool

• Cooling Method: Baseplate cooling / air or liquid cooling

• Weight: approx. 0.9 kg

• Certifications: CE, UL, RoHS

Key Features & Advantages

1. High efficiency and low losses through optimized IGBT and diode design.

2. Excellent thermal performance ensuring stable long-term operation under heavy load.

3. High electrical isolation for enhanced system safety.

4. Industrial-grade reliability resistant to vibration, temperature, and EMI.

5. Compact modular design for easy installation and maintenance.

6. Wide compatibility with ABB drive systems and third-party controllers.

Application Areas

• Industrial frequency converters and servo drives

• Motor control and regenerative power systems

• UPS and backup power systems

• Power electronic converters (rectifiers/inverters)

• Renewable energy inverters (solar, wind)

• Railway traction and power distribution systems

Precautions

1. Ensure proper heat sink contact with thermal grease applied.

2. Do not exceed rated voltage, current, or junction temperature.

3. Avoid ESD damage by using antistatic protection.

4. Verify correct wiring between control and power terminals.

5. Regularly inspect heat sink and mounting hardware.

6. Store in a dry, dust-free environment away from high temperature and humidity.
