ABB AGDR-61C IGBT Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB AGDR-61C is a high-performance Insulated Gate Bipolar Transistor (IGBT) module designed for industrial inverters, servo drives, and power electronic devices. It integrates IGBT switches and freewheeling diodes, providing high efficiency, low loss, and reliable operation under high-speed switching conditions.

The AGDR-61C is suitable for ABB industrial automation, drive systems, and renewable energy/power electronics applications, serving as a key component in high-power, high-reliability systems.

2. Technical Specifications

• Model: AGDR-61C

• Product Type: IGBT Power Module

• Rated Voltage: 600 V DC

• Rated Current: 61 A

• IGBT Count: Single module configuration

• Integrated Diode: Built-in freewheeling diode

• Power Loss: Low power loss (depends on current and switching frequency)

• Operating Temperature: -40°C to +150°C

• Storage Temperature: -40°C to +125°C

• Package Type: Modular package with heatsink base

• Insulation Voltage: >2500 V

• Mounting: Bolt-mounted to heatsink

• Switching Response: Low latency, high-speed switching

3. Features & Advantages

• High-speed switching performance for improved efficiency and lower switching loss

• High power density for compact industrial systems

• Integrated freewheeling diode simplifies circuit design and enhances reliability

• Industrial-grade durability for high temperature and vibration conditions

• Modular package for easy installation and maintenance

• Optimized transistor structure for high efficiency and low power loss

4. Application Areas

• Industrial inverters and servo drives

• Power electronic switching systems

• ABB motor drive systems

• Renewable energy power electronics (solar inverters, wind turbines)

• UPS and battery energy management systems

• High-performance industrial automation control systems

5. Precautions

1. Verify module rated voltage and current match system design requirements before installation.

2. Use appropriate heatsinks to ensure proper module cooling.

3. Avoid overcurrent or short circuit operation to prevent IGBT damage.

4. Avoid direct exposure to high humidity or corrosive environments; provide protective measures if needed.

5. Regularly check module operation and cooling to ensure stable performance.

6. Module is intended for industrial power electronics systems only; not suitable for non-industrial applications.

The structure and details of the product：

Please make an inquiry for more models
