ABB AF30-30-00-11 Contactor

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Overview

The ABB AF30-30-00-11 is an AC contactor used for remote switching and control of motors, heaters, and lighting loads in low-voltage AC circuits. It can be combined with thermal overload relays to form a complete motor protection system and is widely used in industrial automation and machinery applications.

Technical Specifications

• Model: AF30-30-00-11

• Type: AC Contactor

• Rated Operational Voltage (Ue): AC 400 V

• Rated Operational Current (Ie): AC-3 30 A

• Coil Voltage: 24 V DC / 230 V AC (depending on version)

• Poles: 3P (three-pole)

• Mechanical Life: ≥ 10,000,000 operations

• Electrical Life: ≥ 1,000,000 operations (AC-3 load)

• Mounting: DIN rail or screw mounting

• Standards: IEC 60947-4-1

• Protection Rating: IP20

• Dimensions (W×H×D): approx. 45 × 85 × 75 mm

• Additional Features: Optional auxiliary contacts (NO/NC)

Advantages and Features

1. Reliable Motor Control
   High AC-3 rated current suitable for various industrial motor applications.

2. Long Lifespan
   High mechanical and electrical life for frequent operation environments.

3. Flexible Installation
   Can be mounted on DIN rail or fixed with screws for convenient layout.

4. Modular Compatibility
   Compatible with thermal overload relays and auxiliary contacts for versatile control setups.

5. Industrial-Grade Design
   Robust structure suitable for vibration and standard industrial environments.

Typical Applications

• Industrial motor control systems

• Motor starting and protection

• Industrial automation equipment

• HVAC system control

• Lighting and heating load control

Precautions

1. Coil Voltage Matching
   Ensure coil voltage matches the control system.

2. Rated Current Use
   Verify contactor rated current matches load requirements to avoid overload.

3. Proper Installation
   Mount securely on DIN rail or with screws to ensure reliable operation.

4. Environmental Considerations
   Avoid high humidity or corrosive environments; apply protection if needed.

5. Periodic Maintenance
   Check main and auxiliary contacts to ensure reliable operation and switching.
