ABB AF265-30-11-13 1SFL547002R1311 Contactor

1. Key Parameters

• Product Model: ABB AF265-30-11-13 (Ordering Part Number: 1SFL547002R1311)
• Product Series: ABB AF-Series Heavy-Duty AC Contactors (High-Power Load Switching)
• Core Function: Switches high-power AC loads (e.g., large 3-phase motors); provides advanced arc suppression during contact operation; enables remote control via low-voltage coil signals; integrates with overload relays for comprehensive motor protection; supports frequent switching in heavy-duty applications
• Electrical & Switching Specifications:

  Parameter	Details	Performance Metrics
  Main Contacts (Power Circuit)	- Configuration: 3 Normally Open (NO) contacts (3-phase) - Rated Operational Current (Ie): 265A (AC-3 duty, 400V); 160A (AC-3 duty, 690V) - Rated Making Current: 2650A (peak, 400V) - Rated Breaking Current: 1325A (rms, 400V) - Rated Voltage (Ue): 690V AC (max) - Duty Cycle: AC-3 (motor starting, running, stopping—120 starts/hour)	High AC-3 duty rating handles heavy-duty motor applications; 265A current capacity suits large motors (up to 132kW at 400V)
  Auxiliary Contacts (Control Circuit)	- Configuration: 1 Normally Open (NO) + 1 Normally Closed (NC) - Rated Current: 10A (AC-15, 230V); 6A (DC-13, 24V) - Voltage Rating: 250V AC / 60V DC	Built-in auxiliary contacts simplify control logic (e.g., interlocks, status feedback) without additional modules
  Coil Specifications	- Voltage Ratings (Selectable): 24V DC, 110V AC, 230V AC, 400V AC - Coil Power Consumption: 12VA (no-load); 120VA (pick-up) - Coil Resistance: 10Ω (24V DC); 4.2kΩ (230V AC) - Dielectric Strength: 3kV AC (coil to frame, 1 minute)	Wide voltage range supports global electrical systems; robust coil design withstands voltage fluctuations in industrial grids

• Mechanical & Environmental Specifications:

  Parameter	Details	Performance Metrics
  Mechanical Design	- Dimensions: 180mm (W) × 220mm (H) × 150mm (D) - Mounting Type: 35mm DIN rail (EN 50022) or panel mount (via studs) - Housing Material: Flame-retardant thermoplastic (UL 94 V0) with metal reinforcing - Weight: Approximately 3.2kg - Arc Suppression: Multi-chamber arc extinguishing system (ceramic material)	Heavy-duty construction withstands high mechanical stress; ceramic arc chambers ensure efficient arc extinction, extending contact life to 1.2 million+ operations (AC-3 duty)
  Environmental Ratings	- Operating Temperature Range: -30℃~+70℃ (-22℉~158℉) - Storage Temperature Range: -40℃~+85℃ (-40℉~185℉) - Humidity Tolerance: 5%~95% RH (non-condensing, 40℃) - Vibration Resistance: 10~50Hz, 1.5g acceleration (IEC 60068-2-6) - Shock Resistance: 30g (11ms half-sine, IEC 60068-2-27)	Extreme temperature range suits unconditioned industrial environments (e.g., foundries, outdoor pump stations); vibration tolerance prevents contact chatter

• Compliance Standards: CE, UL 508, CSA C22.2 No.14, IEC 60947-4-1, RoHS, EN 61000-6-2 (EMC immunity) |

2. Core Features

• High-Power AC-3 Duty Rating: 265A rated current at 400V (AC-3)—specifically designed for heavy-duty motor control (up to 132kW), handling frequent starts/stops (120 starts/hour) in applications like large compressors and water pumps.
• Robust Arc Suppression: Multi-chamber ceramic arc extinguishing system—rapidly extinguishes electrical arcs during contact operation, reducing contact erosion and extending service life to 1.2 million+ operations, lowering maintenance costs.
• Integrated Auxiliary Contacts: 1NO+1NC auxiliary contacts (10A AC-15)—eliminate the need for add-on contact blocks, simplifying control logic for interlocks (e.g., emergency stop circuits) and status monitoring (e.g., "motor running" indicators).
• Global Voltage Compatibility: Coil options from 24V DC to 400V AC—suits diverse electrical systems worldwide (e.g., 400V AC in industrial plants, 24V DC in control cabinets), reducing inventory complexity for global operations.
• Heavy-Duty Construction: Flame-retardant UL 94 V0 housing with metal reinforcing—withstands mechanical stress from high current loads and vibration, ensuring reliability in rugged environments (e.g., mining, steel mills).
• Wide Temperature Range: -30℃~+70℃ operating range—functions reliably in extreme conditions, from cold storage facilities to high-temperature industrial ovens, without performance degradation.
• Seamless Protection Integration: Compatible with ABB TA/TMAX overload relays—forms a complete motor protection system (overcurrent, overload, phase loss), meeting IEC 60947-4-1 safety standards.

3. Application Fields

• Heavy Industry & Manufacturing: High-power motor control:
  • Steel Mills: Controls large rolling mill motors (up to 132kW)—265A capacity handles high inrush currents; ceramic arc chambers withstand frequent switching during steel forming cycles.
  • Cement Plants: Switches power to kiln drive motors and conveyor systems—wide temperature range (-30℃~+70℃) tolerates plant heat; vibration resistance prevents contact failure near grinding equipment.
• Water & Wastewater Utilities: Large pump control:
  • Water Treatment Plants: Controls high-capacity booster pumps (100kW~132kW)—AC-3 duty handles daily start/stop cycles; auxiliary contacts integrate with level sensors for automatic operation.
  • Sewage Pumping Stations: Switches submersible pump motors in harsh environments—flame-retardant housing reduces fire risk; 95% humidity tolerance suits damp pump houses.
• Energy & Power Generation: Turbine & generator auxiliaries:
  • Power Plants: Controls boiler feedwater pumps and induced draft fans—high breaking current (1325A) handles motor inrush; compatibility with overload relays prevents damage during grid fluctuations.
  • Wind Farms: Switches power to pitch control motors and transformer cooling fans—-30℃ operation ensures reliability in cold climates; robust construction withstands turbine vibrations.
• Building & Infrastructure: Large HVAC & equipment:
  • Commercial Complexes: Controls large chiller compressors and air handling units—230V/400V coil options fit building electrical systems; auxiliary contacts integrate with BMS for energy management.
  • Airports & Stadiums: Switches power to large escalator drives and irrigation pumps—high duty cycle (120 starts/hour) handles peak demand periods; wide voltage range tolerates grid variations.
•
•

The structure and details of the product：
