ABB AF16-30-10-11 Three-pole contactor

•

• 1. Product Overview

  The ABB AF16‑30‑10‑11 Three-Pole Contactor is a compact, modular AC contactor designed for controlling three-phase AC motors and loads. It provides high reliability and long service life, suitable for industrial automation, machinery control, and low-voltage electrical control systems. The built-in auxiliary contact can be used for control logic feedback or signal extension and can be expanded with additional auxiliary modules for more complex control functions.

  ---

  2. Technical Specifications

  • Model: AF16‑30‑10‑11

  • Type: AC Contactor

  • Poles: 3 poles (3 NO)

  • Built-in Auxiliary Contacts: 1 NO

  • Rated Insulation Voltage (Ui): 690 V AC

  • Rated Impulse Withstand Voltage (Uimp): 6 kV

  • Rated Operational Current AC‑3: 16 A

  • Rated Operational Power AC‑3:

    • 220–240 V: ~3 kW

    • 380–400 V: ~7.5 kW

    • 415 V: ~7.5 kW

    • 440–500 V: ~5.5–7.5 kW

    • 690 V: ~7.5 kW

  • Thermal Current (Ith): 30 A

  • Frequency: 50 / 60 Hz

  • Control Coil Voltage: Various options (24 V, 110 V, 220–240 V AC)

  • Electrical Durability: ≥ 1,000,000 operations

  • Mechanical Durability: ≥ 10,000,000 operations

  • Protection Rating: IP20

  • Terminal Type: Screw terminals

  • Dimensions (W×D×H): ~45 × 70 × 80 mm

  • Weight: ~0.35 kg

  ---

  3. Advantages and Features

  • Compact modular design for space-saving installation.

  • High reliability and durability suitable for frequent industrial operations.

  • Auxiliary contact with expandability for additional control logic and feedback.

  • IEC 60947 compliant for safety, insulation, and long-term reliability.

  • Multiple coil voltage options for flexible control system integration.

  ---

  4. Typical Applications

  • Industrial automation motor start/stop control

  • Machinery power circuit control

  • Fans, pumps, compressors, and other motor-driven equipment

  • Production line and conveyor system power distribution

  • PLC / DCS actuators and logic control

  • Low-voltage electrical control in building and facility systems

  ---

  5. Installation & Usage Notes

  • Ensure control coil voltage matches supply voltage before installation.

  • Make firm connections to avoid poor contact, overheating, or misoperation.

  • For high-frequency switching loads, use suitable protective devices.

  • Maintain proper ventilation in control panels to prevent overheating.

  • Disconnect power before maintenance and periodically inspect main and auxiliary contacts for wear.

•
•
•

The structure and details of the product： ​
