ABB AF140-40-11-13 4-Pole Contactor

1. Key Parameters

• Product Model: AF140-40-11-13
• Product Series: ABB AF Series 4-Pole Contactors (LV Load Switching, Industrial Grade)
• Core Function: Switches 3-phase/4-wire electrical loads (motors, heaters, power distribution); provides remote control via coil activation; supports auxiliary contact expansion for status monitoring/interlocking; ensures safe load interruption with arc suppression
• Electrical & Switching Specifications:

  Parameter	Details	Performance Metrics
  Power Ratings	- Rated Operational Current (I<sub>e</sub>): 140A (AC-3 duty, 400V AC) - Rated Making Current: 10×I<sub>e</sub> (1400A, 400V AC) - Rated Breaking Current: 8×I<sub>e</sub> (1120A, 400V AC) - AC Duty Cycles: AC-1 (resistive: 200A), AC-3 (motor: 140A), AC-4 (motor starting: 80A)	Handles large 3-phase loads (e.g., 75kW motors at 400V); AC-3 duty rating ensures reliable motor starting/stopping
  Coil Specifications	- Coil Voltage: 24V DC / 110V AC / 230V AC (selectable, per order) - Coil Power Consumption: 75VA (inrush), 10VA (holding) - Coil Insulation Class: Class F (155℃) - Coil Protection: Surge suppression diode (for DC coils)	Low holding power reduces energy consumption; Class F insulation withstands high ambient temperatures
  Contact Configuration	- Main Contacts: 4 poles (P1-P2, P3-P4, P5-P6, P7-P8) - Auxiliary Contacts: 1 NO (Normally Open) + 1 NC (Normally Closed) (built-in) - Contact Material: Silver-nickel (AgNi) for main contacts; silver-tin oxide (AgSnO₂) for auxiliary contacts - Arc Suppression: Built-in arc chutes (for AC loads)	4 poles enable 3-phase + neutral switching; AgNi contacts resist welding and wear, ensuring 1,000,000 mechanical operations

• Mechanical Specifications:
  • Dimensions: 100mm (W) × 160mm (H) × 120mm (D) (DIN rail-mount)
  • Mounting Type: 35mm standard DIN rail (EN 60715) or direct panel mount
  • Housing Material: Thermoplastic (UL 94 V0, flame-retardant, impact-resistant)
  • Weight: Approximately 1.8kg
  • IP Rating: IP20 (control cabinet installation); IP40 with optional protective cover
• Environmental Ratings:
  • Operating Temperature Range: -25℃~+70℃ (-13℉~158℉)
  • Storage Temperature Range: -40℃~+85℃ (-40℉~185℉)
  • Humidity Tolerance: 5%~95% RH (non-condensing, 40℃)
  • Vibration Resistance: 10~500Hz, 1g acceleration (IEC 60068-2-6)
  • Shock Resistance: 30g (11ms half-sine, IEC 60068-2-27)
• Compliance Standards: CE, RoHS, IEC 60947-4-1 (contactors), UL 508, CSA C22.2 No.14, EN 61326-3-1 (EMC), ABB Motor Control Compatibility Standard

2. Key Features

• 140A High-Current Capacity (AC-3): Rated for 140A at 400V AC-3 duty—controls large 3-phase motors (up to 75kW) and heavy resistive loads (e.g., industrial heaters), eliminating the need for multiple smaller contactors and reducing cabinet space.
• 4-Pole Design: 4 main poles enable 3-phase + neutral switching—ideal for 4-wire systems (e.g., motor circuits with neutral grounding, heater circuits requiring balanced current), ensuring safe and balanced load distribution.
• Built-In Auxiliary Contacts (1NO+1NC): Integrated auxiliary contacts for status monitoring (e.g., "contactor ON" signals to PLCs) or interlocking (e.g., preventing conflicting load activation)—avoids the need for separate auxiliary blocks, simplifying wiring and reducing costs.
• Durable AgNi/AgSnO₂ Contacts: Silver-nickel main contacts resist welding and arc erosion; silver-tin oxide auxiliary contacts ensure low resistance and long life—supports 1,000,000 mechanical operations and 100,000 electrical operations, minimizing maintenance.
• Arc Chute Suppression: Built-in arc chutes safely extinguish electrical arcs during switching—prevents contact damage and fire risk, even when interrupting high currents (e.g., motor inrush currents), complying with IEC 60947-4-1 safety standards.
• Wide Coil Voltage Options: Available with 24V DC, 110V AC, or 230V AC coils—compatible with global control systems (e.g., 24V DC for PLC outputs, 230V AC for direct line control), enabling international deployment.
• Modular Expansion Capability: Accepts ABB auxiliary contact blocks (e.g., CA5-40E) and surge suppressors—expands control functionality (e.g., additional NO/NC contacts) to match complex system requirements, enhancing flexibility.

3. Application Fields

• Large Motor Control: Primary use for 3-phase motor switching:
  • Industrial Pumps & Compressors: Controls 75kW centrifugal pumps (water treatment) or rotary screw compressors (manufacturing)—4-pole design ensures neutral grounding for safety, while AC-3 duty handles frequent start/stop cycles without contact wear.
  • HVAC Fans & Blowers: Switches large HVAC fans in commercial buildings or industrial facilities—built-in auxiliary contacts send "fan running" signals to building management systems (BMS), optimizing energy use and airflow.
• LV Power Distribution: Managing electrical loads:
  • Capacitor Bank Switching: Controls power factor correction (PFC) capacitor banks in LV distribution systems—4-pole design balances current across 3 phases + neutral, while arc chutes prevent capacitor discharge arcs, ensuring stable power factor adjustment.
  • Industrial Heater Control: Switches 3-phase electric heaters (e.g., in plastic extrusion or food processing)—140A capacity handles high resistive loads, and Class F coil insulation withstands high ambient temperatures near heating elements.
• Manufacturing Machinery: Powering production equipment:
  • Conveyor Systems: Controls large conveyor motors in mining or logistics—4-pole grounding enhances safety in dusty environments, while modular expansion (via CA5-40E blocks) adds interlocks to prevent conveyor collision (e.g., between parallel lines).
  • Metal Processing Equipment: Switches motors in metal stamping presses or welding machines—AgNi contacts resist arc erosion from welding-induced voltage transients, ensuring reliable operation in harsh industrial conditions.
• Critical Infrastructure: Ensuring power reliability:
  • Data Center UPS Systems: Switches UPS output to critical server racks—4-pole design supports 3-phase + neutral UPS systems, while auxiliary contacts monitor UPS load status, triggering alarms for overloads.
  • Hospital Medical Equipment: Controls large medical devices (e.g., MRI coolers, sterilization autoclaves)—IP20 protection and flame-retardant housing comply with healthcare safety standards (NFPA 99), ensuring patient and equipment safety.

4. Precautions

• Coil Voltage Compatibility (Critical): Select the correct coil voltage (24V DC/110V AC/230V AC) to match the control circuit—using a 230V AC coil with 24V DC power results in coil failure; verify coil voltage via the product nameplate before installation.
• Installation & Wiring Safety:
  • Wire Size & Torque: Use 16mm²~35mm² copper wires for main contacts (140A load)—undersized wires overheat; torque main terminals to 25Nm (for 35mm² wires) and auxiliary terminals to 2.5Nm (for 2.5mm² wires) to prevent loose connections.
  • Phase & Neutral Alignment: Connect main poles to L1/L2/L3 (3-phase) and N (neutral) correctly—reversing phases may cause motor reversal (e.g., pump direction), while missing neutral connection risks unbalanced current and equipment damage.
  • Surge Protection: For DC coils, ensure the built-in surge suppression diode is functional—without suppression, coil de-energization causes voltage spikes that damage PLC outputs; add external varistors for AC coils in high-noise environments.
• Operation & Maintenance:
  • Duty Cycle Compliance: Do not exceed AC-3/AC-4 duty cycle limits—using AC-1 rated loads (resistive) beyond 200A or AC-4 motor loads beyond 80A causes contact overheating and premature failure; refer to ABB’s duty cycle chart for load limits.
  • 定期检查: Perform quarterly inspections for:
    • Contact wear (check for pitting or discoloration—replace if contact thickness is <50% of original)
    • Coil overheating (feel for excessive warmth—indicates coil damage or incorrect voltage)
    • Arc chute integrity (ensure chutes are not cracked or clogged with dust—clean with compressed air)
    • Auxiliary contact operation (test NO/NC continuity with a multimeter—replace if contacts are stuck)
  • Lockout/Tagout (LOTO): Always apply LOTO procedures before servicing downstream equipment—never rely on the contactor’s "Off" position; use the contactor’s mounting bracket to secure LOTO locks, preventing accidental energization.
• Environmental Limitations:
  • Temperature & Humidity: Avoid operation below -25℃ (coil resistance increases, reducing holding force) or above +70℃ (contact resistance rises)—install cabinet heaters in cold environments and dehumidifiers in tropical regions to maintain operating range.
  • Dust & Chemical Exposure: Use an optional IP40 cover in dusty (mining) or chemical (refineries) environments—dust accumulation on contacts increases resistance, while chemicals degrade thermoplastic housing; clean contacts annually with a dry brush (no solvents).
• Replacement & Spare Parts:
  • Genuine ABB Components: Use only genuine AF140-40-11-13 contactors and ABB-approved spare parts (e.g., coils, contacts)—non-genuine contacts have poor arc resistance (fail after 10,000 operations vs. 100,000 for genuine), leading to unexpected downtime. Verify authenticity via ABB’s serial number lookup tool.
  • Spare Inventory: Maintain 1 spare contactor per 5 critical applications (e.g., pumps, compressors)—critical for minimizing downtime in production lines where motor failure halts operations; store spares in dry, temperature-controlled conditions to preserve coil and contact integrity
