ABB AF12-30-01-13 1SBL157001R1301 Contactor

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• • 1. Product Overview

    The ABB AF12-30-01-13 (1SBL157001R1301) is an AC contactor designed for low-voltage power systems to control motors, electric heaters, and lighting loads. It provides reliable switching performance and long mechanical life, supporting remote control and integration with automation systems. The modular design allows combination with accessories such as auxiliary contacts, mechanical interlocks, and overload protection.

    ---

    2. Technical Specifications

    Parameter	Description
    Model	AF12-30-01-13 / 1SBL157001R1301
    Type	AC Contactor
    Poles	3P (3 poles)
    Rated Current	12 A AC-3
    Rated Operational Voltage	690 V AC
    Coil Voltage	24–400 V AC / 24–60 V DC (depending on version)
    Coil Power	AC 5–7 W / DC 4–6 W (typical)
    Breaking Capacity	According to IEC 60947-4-1
    Auxiliary Contacts	Optional 1 NO + 1 NC
    Mounting	DIN rail or screw mounting
    Mechanical Life	≥ 1,000,000 operations
    Electrical Life	≥ 100,000 operations (AC-3 load)
    Protection	IP20
    Housing Material	Flame-retardant plastic
    Operating Temperature	-25℃ to +60℃
    Standards	IEC 60947-4-1 / EN 60947-4-1

    ---

    3. Key Advantages & Features

    1. High Reliability

       • Precision contacts and high-durability coil ensure stable long-term operation.

    2. Wide Applicability

       • Suitable for controlling motors, lighting, and electric heaters.

    3. Modular Design

       • Compatible with auxiliary contacts, overload relays, and mechanical interlocks for flexible control schemes.

    4. Long Lifespan

       • Mechanical life ≥ 1,000,000 operations, electrical life ≥ 100,000 operations (AC-3 load).

    5. Easy Installation

       • DIN rail or screw mounting for convenient panel layout and maintenance.

    ---

    4. Typical Applications

    • Industrial motor control systems

    • Automated production lines

    • HVAC motors, fans, and pumps control

    • Power distribution and lighting systems

    • Remote control of machinery and mechanical equipment

    ---

    5. Usage Precautions

    • Installation: Must be installed by qualified electricians; ensure correct wiring and proper coil voltage.

    • Load Matching: Load current must not exceed the contactor rating to ensure proper switching.

    • Environmental Conditions: Avoid high temperature, humidity, dust, and corrosive environments.

    • Maintenance: Periodically check contact wear and screw tightness.

    • Operational Safety: Ensure coil is de-energized before switching the load to prevent arcing or electric shock.

  •

The structure and details of the product：
