ABB AF100 3BSE020520R1 Fieldbus Communication Interface

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB AF100 3BSE020520R1 is a high-performance Fieldbus Communication Interface designed for data exchange between controllers and field devices in industrial automation systems. The interface module supports multiple industrial fieldbus protocols, providing high-speed, reliable data transmission and remote device monitoring. The AF100 offers easy installation, stable communication, and strong interference immunity, making it a key data connectivity component in modern industrial control systems.

2. Technical Specifications

• Model: AF100 3BSE020520R1

• Product Type: Fieldbus Communication Interface

• Supported Protocols: Profibus DP, Modbus RTU, DeviceNet (system dependent)

• Interface Type: RS485 / Optional fiber optic

• Data Transmission Rate: 12 Mbps (Profibus DP)

• Supply Voltage: 24 V DC

• Power Consumption: ≤ 5 W

• Operating Temperature: -20 ℃ to +60 ℃

• Degree of Protection: IP20

• Mounting: DIN rail or panel mount

• Dimensions (Approx.): H 110 mm × W 50 mm × D 40 mm

• Standards Compliance: CE, IEC 61158, UL

3. Advantages & Features

1. Multi-Protocol Compatibility
   Supports Profibus, Modbus, DeviceNet, and other industrial fieldbus protocols.

2. High-Speed, Reliable Communication
   Up to 12 Mbps data rate ensures real-time data exchange.

3. Industrial-Grade Reliability
   Resistant to vibration and electromagnetic interference, suitable for harsh industrial environments.

4. Flexible Installation
   DIN rail or panel mount design for easy system integration.

5. Easy Configuration & Maintenance
   Modular design with clear terminals and indicators simplifies installation, commissioning, and maintenance.

6. Energy Efficient
   Low power consumption reduces system energy usage and improves overall efficiency.

4. Application Areas

The ABB AF100 3BSE020520R1 Fieldbus Communication Interface is widely used in:

• Industrial automation control systems

• PLC, DCS, and field device connectivity

• Power, petrochemical, chemical, and pharmaceutical process control

• Production line monitoring and data acquisition systems

• Water and wastewater treatment plant control systems

• Robotics and automated equipment communication interface

5. Notes & Precautions

1. Ensure power is disconnected before installation to avoid electrical hazards.

2. Communication interfaces must match device voltage and current ratings to prevent module damage.

3. Install in a dry, ventilated environment, avoiding dust, moisture, and corrosive gases.

4. Regularly inspect terminals and communication lines to ensure stable data transmission.

5. Installation, commissioning, and maintenance should be performed by qualified electrical engineers.

6. Avoid long-term operation in strong electromagnetic interference environments; shielding may be required.
