ABB AF09-30-10-13 Three-pole contactor

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB AF09-30-10-13 Three-pole Contactor is an electrical switching device used for controlling AC motors, electric heaters, and lighting loads. It features a high-performance coil and contact system, enabling remote switching in low-voltage distribution systems. Its modular construction and reliable contacts make it suitable for industrial and commercial applications.

2. Technical Specifications

• Model: AF09-30-10-13

• Product Type: Three-pole Contactor

• Rated Operational Voltage: AC 690 V

• Rated Operational Current: 9 A

• Coil Control Voltage: AC 230 V / 50-60 Hz

• Contact Configuration: 3 NO (Normally Open)

• Mechanical Life: ≥ 10,000,000 operations

• Electrical Life: ≥ 1,000,000 operations

• Mounting Method: DIN rail or bolt-mounted

• Insulation Class: F

• Protection Class: IP20

• Operating Temperature: ‑25 ℃ to +55 ℃

• Standards: IEC 60947-4-1, UL, CE

3. Advantages and Features

1. Reliable Contact System
   Wear-resistant contact material ensures long life and stable performance.

2. Remote Control
   The coil voltage allows remote switching of motors or loads.

3. Modular Design
   Easy installation and maintenance; can be combined with auxiliary contacts and overload relays.

4. Durable
   Industrial-grade design supports long-term continuous and high-frequency operation.

5. Enhanced Safety
   IP20 protection reduces the risk of accidental operation, ensuring operator safety.

6. Wide Compatibility
   Suitable for AC motors, lighting, electric heating, and general load control.

4. Typical Applications

• Industrial AC motor control

• Lighting distribution systems

• Electric heater switching control

• Automated production lines and machinery

• Distribution and control panels

• OEM industrial equipment

5. Installation and Usage Notes

1. Verify that the rated current, voltage, and coil voltage match the system before installation.

2. Power off during wiring to ensure personnel safety and equipment protection.

3. Avoid prolonged use in high humidity, high temperature, or corrosive environments; provide protection if necessary.

4. Regularly inspect mechanical movement, contact condition, and fastening to ensure reliable operation.

5. Use with overload protection devices to extend the life of motors and equipment.
