1. Product Overview

The ABB AF09-30-10-11 (1SBL137001R1110) is a 3-pole AC contactor designed for industrial automation and small motor control. Compact, reliable, and easy to operate, it is suitable for controlling small motors, lighting, heaters, and general industrial control loads.

2. Technical Specifications

• Model: AF09-30-10-11

• ABB Part Number: 1SBL137001R1110

• Brand: ABB

• Type: 3-Pole AC Contactor

• Rated Current: 9 A (AC-3, inductive load)

• Rated Coil Voltage: AC 230 V / 50–60 Hz (coil voltage configurable)

• Number of Poles: 3P

• Contact Configuration: 3 NO (normally open) contacts

• Mechanical Life: ~1,000,000 operations

• Electrical Life: ~100,000 operations (rated load)

• Operation: Electromagnetic coil

• Protection Rating: IP20

• Mounting: DIN rail or screw mounting

• Auxiliary Contacts: Optional

• Load Types: Small motors, lighting, heaters, and control circuits

3. Key Advantages & Features

1. Compact Design – Space-saving for installation in control panels.

2. High Reliability – High-quality contacts ensure stable long-term operation.

3. Easy Operation – Electromagnetic coil provides reliable switching.

4. Versatile Application – Suitable for small motors, lighting, and general control loads.

5. Energy Efficient – Low coil power reduces energy consumption and heat.

6. Safe & Reliable – Can be used with overload relays or protective devices for enhanced safety.

4. Typical Applications

• Small motor control

• Industrial automation equipment

• Lighting and heater control

• Control panels and distribution systems

• HVAC systems and building electrical control

• Laboratory or test equipment control

5. Installation & Usage Notes

1. Power Matching – Ensure coil voltage matches the rated voltage.

2. Wiring & Fixing – Secure contact connections to avoid poor contact.

3. Environmental Conditions – Avoid high humidity, dust, and corrosive gases; ensure ventilation.

4. Operation – Avoid frequent manual switching under load; ensure proper coil operation.

5. Regular Inspection – Check contact wear and wiring for long-term reliable operation.
