ABB ADPI-01 Analog Interface Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Technical Specifications

• Model: ADPI-01

• Function: Analog and pulse/encoder signal interfacing

• Analog Inputs: 2 channels, supporting 0–10 V (voltage) or 0/4–20 mA (current) signals

• Analog Output: 1 channel, 0–10 V output

• Pulse / Encoder Input: supported, up to 100 kHz input frequency

• Operating Temperature: 0 °C to +55 °C

• Mounting Method: Panel-mount / control-panel integration

• Weight: Approximately 1.35 kg

• Origin: Sweden

Advantages & Features

• Multi-signal compatibility: Handles both analog (voltage/current) and pulse/encoder signals — making it versatile for various sensor types and feedback devices.

• Encoder / pulse input support: With up to 100 kHz input frequency, well-suited for applications requiring motor speed or position feedback, ensuring accurate and timely responses.

• Robust industrial-grade design: Engineered for stable and durable operation in industrial control environments; suitable for integration into control panels or cabinets.

• Easy integration with ABB systems: Works as a panel interface board, facilitating seamless integration with ABB drives or automation/control systems.

• Compact and space-efficient: Small footprint enables flexible installation even within space-constrained control cabinets or equipment enclosures.

Typical Application Areas

• Industrial automation & drive systems: Use with VFD, servo drives, motor control systems — to accept analog sensor signals or encoder/pulse feedback for control and monitoring.

• Process control / Instrumentation: Connect analog-output sensors (e.g. pressure, temperature, flow, level) and feed signals to PLC / DCS / drive systems for process monitoring and control.

• Motion control & feedback systems: Suitable for machinery or equipment needing precise position/speed feedback (e.g. conveyors, robots, material handling, packaging lines).

• General automation I/O integration: Serves as a general-purpose interface module when a mix of analog input, analog output and pulse/encoder input is required.

Usage Notes / Recommendations

• Ensure input signals (voltage or current) remain within specified ranges (0–10 V / 0/4–20 mA) — exceeding limits may damage the module or yield inaccurate readings.

• For pulse/encoder inputs, ensure the encoder’s output frequency does not exceed 100 kHz to guarantee correct detection and stable operation.

• Install module inside control cabinets or control panels (panel-mount), avoiding exposure to moisture, dust, or strong electromagnetic interference for longevity and reliability.

• Pay attention to wiring and grounding — apply proper shielding and grounding for analog and encoder/pulse signal lines to minimize electrical noise or interference, especially near high-power equipment.

• Maintain ambient operating temperature between 0 °C and +55 °C; if the installation environment is outside this range, consider environmental control or alternative modules.

The structure and details of the product：

Please make an inquiry for more models
