ABB ACS800-04-0040-3+J400 Driver Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Overview

The ABB ACS800-04-0040-3+J400 is a low-voltage high-performance AC drive module designed for industrial automation, pumps, fans, motor control, and various machinery. It provides precise speed and torque control, supports multiple communication protocols, and offers comprehensive protection functions for efficient, reliable, and energy-saving motor operation.

Main Technical Specifications

• Model: ACS800-04-0040-3+J400

• Product Type: Low Voltage AC Drive Module

• Rated Input Voltage: 380–480 V AC, 3-phase

• Rated Output Voltage: 0–480 V AC

• Rated Output Current: 40 A

• Rated Motor Power: 22 kW

• Control Modes: V/f control, vector control (with/without encoder), PID control

• Frequency Range: 0–599 Hz

• Overload Capacity: 150% for 1 minute

• Start/Stop Type: Soft start / soft stop

• Communication Interfaces: Modbus RTU / Profibus / Ethernet optional

• Protection Functions: Overcurrent, overvoltage, undervoltage, stall, overheating, phase loss

• Protection Class: IP21 (optional IP55 enclosure)

• Operating Temperature: -10 ℃ to +50 ℃

• Ambient Humidity: 0–95% RH, non-condensing

• Dimensions (HxWxD): approx. 500×300×230 mm

• Standards: CE, UL, cUL, IEC 61800-5-1

Key Advantages & Features

1. High-Performance Motor Control
   Supports V/f and vector control for high-precision speed and torque, suitable for diverse industrial loads.

2. Energy Efficient
   Precise motor regulation reduces energy consumption and improves system efficiency.

3. Multi-Protocol Communication
   Supports Modbus, Profibus, and Ethernet for easy integration with PLCs, HMIs, and automation systems.

4. Comprehensive Protection Functions
   Built-in protections ensure safe operation of both motor and drive under abnormal conditions.

5. Flexible Installation and Operation
   Modular design allows easy installation, with intuitive control panel and quick commissioning.

6. Industrial-Grade Reliability
   Designed for wide temperature and humidity ranges, providing long-term stable operation.

Typical Applications

• Industrial automation production lines

• Conveyor and logistics systems

• Pump and fan control systems

• HVAC systems

• Packaging machinery and food & beverage processing equipment

• Metallurgical and mining machinery

• Manufacturing and processing equipment

Installation & Operation Notes

• Ensure input voltage matches the motor’s rated voltage

• Install in a well-ventilated, dry environment; avoid dust, high temperature, and corrosive gases

• Set motor parameters according to the manual and ensure proper grounding

• Regularly check heat sinks and fans to maintain effective cooling

• Avoid prolonged overload operation to prevent overheating

• Do not remove or service the module while powered on
