ABB ACS800-04-0025-3 Inverter Drive

Introduction

The ABB ACS800-04-0025-3 is a compact wall-mounted variable frequency drive (VFD) from the ACS800 series. It is designed for industrial motor control, energy optimization, and flexible automation requirements. This model is suitable for three-phase AC motors and is widely used across industrial sectors.

Technical Specifications

• Model: ACS800-04-0025-3

• Rated Power: ~ 11 kW (15 HP)

• Rated Current: 25 A

• Input Voltage: 3-phase, 380 – 415 V AC, 50/60 Hz

• Output Voltage: 0 – 100% of input (adjustable)

• DC Link Voltage: ~ 500 – 800 V DC

• Control Modes:

  • Direct Torque Control (DTC)

  • Scalar (V/Hz)

• Overload Capacity: 150% for 1 minute

• Protection Class: IP21 standard, optional IP54

• Cooling: Forced air cooling

• Interfaces:

  • Standard I/O (DI/DO/AI/AO)

  • Optional fieldbus modules (Profibus, DeviceNet, Modbus, CANopen, EtherNet/IP)

• Ambient Conditions:

  • Operating temperature: –10 °C ~ +40 °C (derating up to +50 °C)

  • Mounting: Wall-mounted

Features & Advantages

• DTC technology for high precision torque and speed control.

• Energy efficiency optimization reduces operating costs.

• Flexible expansion with optional communication and I/O modules.

• User-friendly operation with optional control panels.

• High reliability designed for continuous operation.

• Compact design saves space in control cabinets.

Applications

• Pumps

• Fans

• Conveyors

• Cranes & Hoists

• Machine Tools

• Pulp & Paper, Metals, Chemical industries

Installation & Maintenance Notes

1. Ensure supply voltage matches 380–415 V rating.

2. Use with properly sized motor (11 kW / 25 A).

3. Provide adequate ventilation and cooling.

4. Use braking chopper & resistor when fast braking is required.

5. Installation and commissioning should be performed by qualified personnel.
