ABB ACS800-01-0060-3+E200+N687 Drive

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB ACS800 series is a high-performance industrial AC drive designed for precise speed and torque control of AC motors, suitable for pumps, fans, compressors, conveyors, and other industrial applications. The model ACS800-01-0060-3+E200+N687 features the E200 control module and N687 function module, supporting adaptive control, regenerative braking, network communication, and multiple protection functions, ideal for demanding industrial automation and energy-saving control scenarios.

2. Technical Specifications

• Model: ACS800-01-0060-3+E200+N687

• Product Type: Industrial AC Drive

• Rated Power: 60 kW

• Input Voltage: 380–480 V AC, three-phase, 50/60 Hz

• Output Voltage: 0–input voltage AC

• Output Current: 115 A

• Control Module: E200 (advanced control features, PID control, energy optimization)

• Function Module: N687 (network and communication expansion, e.g., Profibus, Modbus, DeviceNet)

• Frequency Range: 0–590 Hz

• Control Method: Sensorless Vector Control (SVC)

• Overload Capacity: 150% for 1 minute

• Protection Functions: Overload, short circuit, overvoltage, undervoltage, phase loss, overtemperature

• Operating Temperature: -10 ℃ to +50 ℃

• Cooling Method: Air cooling

• Mounting: Wall-mounted / Cabinet-mounted

• Standards Compliance: IEC 61800-5-1, IEC 60947-4-1, CE

3. Key Advantages & Features

• High-Performance Control – Sensorless vector control for precise speed and torque regulation.

• Energy Saving – Built-in energy optimization for pumps and fans.

• Rich Communication Interfaces – N687 module supports Profibus, Modbus, DeviceNet.

• Flexible Installation – Modular design allows wall or cabinet mounting.

• Multiple Protection Functions – Overload, short circuit, overvoltage, undervoltage, etc.

• Extended Functions – E200 module offers PID control, adaptive adjustment, regenerative braking.

• High Reliability & Durability – Industrial design suitable for harsh operating conditions.

4. Typical Applications

• Industrial pumps and fans

• Conveyors and material handling systems

• Compressors and cooling systems

• Paper, chemical, mining, and water treatment industries

• Speed and torque control in automated production lines

• Energy-saving retrofits and high-demand industrial control applications

5. Installation & Usage Notes

• Power Supply Matching – Ensure input voltage is within 380–480 V AC range.

• Cooling & Ventilation – Maintain adequate airflow to prevent overheating.

• Grounding & Protection – Proper grounding according to electrical standards.

• Load Matching – Motor power should match drive rating to avoid overload or tripping.

• Regular Maintenance – Clean heat sinks, check wiring and module status.

• Environmental Requirements – Avoid high humidity, dust, or corrosive environments; use protective measures if necessary.
