ABB ACS800-01-0020-5-E200 Frequency Inverter

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB ACS800-01-0020-5-E200 Frequency Inverter is a high-performance AC motor drive used for precise speed and torque control, enabling energy-efficient operation and optimized process control. This inverter features a modular design, supports multiple control modes including vector control and open-loop V/F control, provides robust protection, communication capabilities, and a user-friendly interface. It is widely used in pumps, fans, compressors, and industrial automation systems.

2. Technical Specifications

• Model: ACS800-01-0020-5-E200

• Product Type: AC Frequency Inverter

• Rated Power: 2 kW

• Rated Voltage: 3 AC 380–480 V

• Rated Current: 5.8 A

• Control Modes: V/F control, Closed-loop vector control

• Output Frequency Range: 0–500 Hz

• Overload Capacity: 150% for 1 minute

• Input Power Supply: 3-phase AC 380–480 V, 50/60 Hz

• Protection Class: IP20 (standard type)

• Operating Temperature: –10 ℃ to +50 ℃

• Cooling Method: Natural or forced air cooling (depending on model)

• Communication Interfaces: Profibus DP, Ethernet/IP, Modbus (optional)

• Mounting: Panel mount / DIN rail (depending on model)

• Standards: CE / UL / IEC 61800-5-1

3. Advantages and Features

1. High-Performance Control
   Supports vector and V/F control for precise speed and torque regulation.

2. Energy Efficiency
   Accurately matches load demand, reduces energy consumption, and extends equipment life.

3. Robust Protection Functions
   Includes overcurrent, overvoltage, undervoltage, overheating, and short-circuit protection.

4. Multiple Communication Protocols
   Supports Profibus, Ethernet/IP, and Modbus for remote monitoring and integration.

5. Modular and Easy Maintenance
   Modular design allows easy expansion, maintenance, and field replacement.

6. User-Friendly Operation
   Intuitive control panel and programmable parameters for easy monitoring and adjustment.

4. Applications

• Industrial pumps, fans, and compressors

• Conveyor systems and automated production lines

• HVAC systems (heating, ventilation, and air conditioning)

• Water and wastewater treatment equipment

• Elevators, cranes, and heavy machinery drives

5. Installation and Usage Notes

1. Ensure the inverter’s rated power, voltage, and motor match before installation.

2. Perform wiring and installation with power disconnected for safety.

3. Maintain proper ventilation; avoid high-temperature, high-humidity, or dusty environments.

4. Regularly check input/output terminals, heat sinks, and cooling fans to ensure proper cooling.

5. Do not modify or disassemble the inverter to avoid affecting control functionality and safety.
