ABB ACS800-01-0004-3+K454 drive

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Overview

The ABB ACS800-01-0004-3 equipped with the K454 control module is a high-performance low-voltage AC drive designed for industrial machinery, motor control, pumps, fans, and conveyor systems. The ACS800 series provides precise speed and torque control, supports multiple industrial control modes, and features advanced protection and communication capabilities, suitable for complex automation and process control systems.

Main Technical Specifications

• Model: ACS800-01-0004-3 + K454

• Product Type: Low Voltage AC Drive

• Rated Input Voltage: 380–480 V AC, 3-phase

• Rated Output Voltage: 0–480 V AC

• Rated Output Current: 4 A

• Motor Power: 0.75 kW

• Control Modes: Vector control (with or without encoder), V/f control, PID control

• Frequency Range: 0–599 Hz

• Overload Capacity: 150% for 1 minute

• Start/Stop Type: Soft start / soft stop

• Communication Interface: Standard Modbus RTU, expandable Profibus, Ethernet/IP

• Protection Class: IP20 (optional IP21/IP54 enclosure)

• Operating Temperature: -10 ℃ to +50 ℃

• Ambient Humidity: 0–95% RH, non-condensing

• Dimensions (HxWxD): approx. 200×150×190 mm

• Standards: CE, UL, cUL, IEC 61800-5-1

Key Advantages & Features

1. Precise Control
   Supports vector and V/f control for accurate speed and torque regulation.

2. Comprehensive Protection
   Built-in overcurrent, overvoltage, undervoltage, overheating, and motor stall protection.

3. Flexible Communication
   Easily integrates into automation systems via Modbus RTU, Profibus, or Ethernet/IP.

4. Energy Efficient
   Optimized motor control reduces energy consumption and improves system efficiency.

5. Compact and Reliable
   Modular design saves space and fits in tight control cabinets or equipment spaces.

6. Easy Installation and Commissioning
   Intuitive control panel and quick parameter setup reduce installation and commissioning time.

Typical Applications

• Industrial machinery control

• Conveyor and material handling systems

• Pump and fan control systems

• Packaging machinery

• HVAC systems

• Light industry and manufacturing lines

• Process automation systems

Installation & Operation Notes

• Ensure input voltage matches motor rated voltage

• Install in well-ventilated, dry, and dust-free environments

• Avoid direct installation in corrosive atmospheres

• Set motor parameters and ensure proper grounding according to the manual

• Regularly check heat sinks and fans for proper cooling

• Avoid prolonged overload operation to prevent overheating or damage
