ABB ACS580-01-363A-4 frequency converter

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB ACS580-01-363A-4 is a high-performance general-purpose industrial frequency converter designed for pumps, fans, conveyors, and a wide range of mechanical equipment. As part of ABB’s ACS580 “All-compatible” series, it is known for its simplicity, reliability, and high energy efficiency. The model 363A-4 supports 380–480V AC input and provides a rated output current of 363A, making it ideal for medium- to high-power industrial loads.

2. Main Technical Specifications

• Model: ACS580-01-363A-4

• Input Voltage: 3-phase 380–480 V AC

• Input Frequency: 50 / 60 Hz

• Rated Output Current: 363 A

• Typical Motor Power: approx. 200–250 kW (depending on load type)

• Control Method: Direct Torque Control (DTC), Energy-optimized mode

• Overload Capacity: 150% for 1 minute

• Protection Class: IP21 (optional IP55)

• Integrated Functions:

  • Built-in EMC filter

  • Built-in brake chopper

  • Built-in PID controller

  • Integrated Modbus RTU communication

• Operating Temperature: –15°C to +50°C (derating may apply)

• Cooling Method: Forced air cooling

• Installation: Wall-mounted

3. Advantages & Features

1. Easy to Use

• Intuitive keypad and startup assistant

• Clear parameter structure for quick commissioning

• Auto-tuning for precise motor control

2. Powerful and Stable Control

• ABB’s patented DTC technology for high dynamic response

• High torque at low speed and smooth output waveform

3. High Energy Efficiency

• Integrated energy optimizer

• Real-time energy monitoring and trend display

4. Industrial-Grade Reliability

• Full protection: overload, short circuit, overtemperature

• Designed for harsh industrial conditions

5. Flexible Communication

• Standard Modbus

• Options available: PROFIBUS, EtherNet/IP, PROFINET, etc.

4. Application Fields

• HVAC systems: fans, chillers, circulation pumps

• Water and wastewater treatment

• Manufacturing and automation: conveyors, mixers, extruders

• Chemical and process industry

• Food and pharmaceutical machinery

• Mining and metals: crushers, conveyors

5. Notes and Precautions

• Ensure correct 380–480V 3-phase power supply

• Long motor cables may require additional filtering

• Ambient temperature above +40°C may require derating

• Maintain proper ventilation and avoid blocking airflow

• Not recommended for corrosive or heavy-dust environments without protective enclosure

• External braking resistor may be needed for high-inertia loads
