  • ABB ACS580-01-169A-4 Variable Speed/Frequency Drive — Product Description

    1. Product Overview

    The ABB ACS580-01-169A-4 is a general-purpose low-voltage variable frequency drive (VFD) for controlling the speed and torque of three-phase AC motors. It provides smooth start/stop, braking, energy-efficient operation, and multiple protection functions. The ACS580 series is compact, user-friendly, and features integrated PLC functionality and communication interfaces for automation and remote monitoring.

    ---

    2. Technical Specifications

    • Model: ACS580-01-169A-4

    • Type: Variable Frequency / Variable Speed Drive

    • Rated Power: 160 kW

    • Input Voltage: 380–480 V AC ±10%

    • Input Current: 199 A

    • Output Voltage: 0–480 V AC

    • Output Current: 169 A

    • Control Modes: V/Hz Control, Vector Control

    • Frequency Range: 0–500 Hz

    • Overload Capability: 150% for 1 min / 180% for 2 sec

    • Protection Functions: Overload, over/under voltage, phase loss, over-temperature, short circuit

    • Communication Interfaces: Modbus RTU, Profibus, EtherNet/IP, optional CANopen

    • Built-in Functions: PLC control, PID, energy saving, auto restart

    • Operating Temperature: -15°C ~ +50°C (derating up to 60°C)

    • Protection Class: IP21

    • Mounting: Wall-mounted or cabinet installation

    • Weight: ~130–150 kg

    ---

    3. Features & Advantages

    • High-performance control: precise vector and V/Hz control for various loads

    • Energy-efficient operation: reduces energy consumption for pumps and fans

    • Integrated protection: overload, over/under voltage, phase loss, over-temperature, short-circuit

    • Flexible communication & automation: supports multiple industrial protocols, built-in PLC

    • Easy installation & operation: compact, intuitive interface for setup and maintenance

    ---

    4. Application Areas

    • Industrial pumps, fans, compressors, conveyors

    • HVAC systems (heating, ventilation, air conditioning)

    • Water and wastewater treatment

    • Elevators, cranes, material handling equipment

    • Automated production lines and process control

    • Energy management and efficiency applications

    ---

    5. Precautions

    • Verify input voltage matches drive specification before installation

    • Install and wire only with power off to ensure safety

    • Use appropriate circuit breakers or fuses for protection

    • Ensure proper cooling in high-temperature or humid environments

    • Regularly inspect cooling fans and heat sinks for dust accumulation

    • Parameter settings should match motor type, load, and application

  •
  •
  •
  •
