ABB ACS550-01-015A-4 frequency converter

Product Name: ABB ACS550-01-015A-4 Variable Frequency Drive

Technical Specifications:

• Input Voltage: 380–480 V AC, 3-phase

• Frequency Range: 47.5–63 Hz

• Rated Output Power: 7.5 kW (10 HP)

• Rated Output Current: 15.4 A (normal use), 11.9 A (heavy-duty use)

• Protection Class: IP21, suitable for indoor installation

• Efficiency Class: IE2

• Mounting Type: Wall-mounted

• Dimensions (W × H × D): 240 × 585 × 400 mm

• Weight: Approximately 9 kg

Advantages and Features:

• Energy Efficiency: Complies with IE2 efficiency standards, reducing energy consumption and meeting international energy regulations.

• Easy Installation and Commissioning: Wall-mounted design with FlashDrop tool for quick and safe parameter setting.

• Intelligent Control Functions: Built-in load analyzer for real-time monitoring of current, torque, etc., optimizing drive system configuration.

• Strong Anti-Interference Capability: Equipped with built-in EMC filter and swinging choke to effectively reduce harmonic interference.

• Strong Adaptability: Supports Modbus communication protocol for easy integration with PLCs and other devices.

• Environmental Adaptability: Features coated circuit boards suitable for harsh environments.

Applications:

The ACS550-01-015A-4 variable frequency drive is widely used in the following industries:

• Pumps and Fans: Adjusts speed to achieve energy savings and flow control.

• Conveyor Systems: Provides smooth speed control in conveyors and elevators.

• Mixing and Stirring Equipment: Ensures uniformity and stability in mixing processes.

• HVAC Systems: Regulates fan and pump operations in heating, ventilation, and air conditioning systems to enhance energy efficiency.

Precautions:

• Environmental Requirements: For indoor use only; avoid high temperatures, humidity, and corrosive environments.

• Power Supply: Ensure input voltage is within the 380–480 V AC range to prevent overvoltage or undervoltage.

• Grounding: Proper grounding is essential for safe operation.

• Maintenance: Regularly check cooling channels and keep the device clean to prevent dust accumulation.

• Communication Settings: When using Modbus communication, ensure correct configuration of communication parameters.

The structure and details of the product：
