ABB ACS355-03E-07A3-4 Low Voltage AC Drive

Product Overview

The ABB ACS355-03E-07A3-4 is a high-performance low-voltage AC drive designed for motor control in various industrial applications. It features a compact design, energy-saving capabilities, and high reliability. The drive uses advanced vector control technology and offers precise speed control, making it ideal for applications requiring fine control over motor speed, torque, and acceleration. The ACS355 is suitable for conveyor systems, pumps, fans, packaging machinery, and other industries, helping to enhance motor efficiency and reduce energy consumption.

This drive is highly flexible, supporting multiple communication protocols, making it easy to integrate into various automation systems. Its compact design allows installation in space-constrained control panels, with easy setup and commissioning, particularly for small to medium-sized machinery and equipment.

Technical Specifications

• Model: ACS355-03E-07A3-4

• Type: Low Voltage AC Drive

• Input Voltage: 380-480V AC (three-phase input)

• Power Range: 0.75 kW - 7.5 kW

• Output Voltage: Synchronous output, depends on input voltage and load

• Frequency Range: 0-500 Hz

• Control Method: Vector Control (Flux Vector Control) or V/F control

• Speed Control Range: Offers a wide speed control range for different applications

• Overload Capacity: 150% rated current overload capacity

• Communication Protocols: Supports Modbus RTU, CANopen, Ethernet/IP, and more

• Operating Temperature Range: -10°C to 50°C

• Dimensions: Compact design, suitable for standard control panel installation

• Protection Rating: IP20 (for indoor use only)

• Efficiency: High-efficiency design to reduce energy consumption and enhance motor performance

Advantages & Features

1. Compact Design: Space-saving, compact form factor, ideal for installations with limited space in control panels.

2. Energy Efficient: Uses advanced vector control technology to optimize motor efficiency and reduce energy consumption, ideal for energy-saving applications.

3. High Overload Capability: Can handle 150% rated current overload, suitable for frequent start/stop and high-load operations.

4. Precise Control: Offers precise speed, acceleration, and torque control for a wide range of applications requiring fine control.

5. Multi-Protocol Communication: Supports Modbus RTU, CANopen, Ethernet/IP, and other communication protocols, facilitating integration with different automation systems.

6. Ease of Installation & Commissioning: Simple operation and easy installation, especially suitable for small to medium equipment.

7. Built-in Protection Features: Includes overload, overheat, short-circuit, and overvoltage protection to ensure system stability and safety.

8. High Reliability: Built with ABB’s high-quality power electronics, ensuring stable operation even in harsh industrial environments.

Application Fields

1. Industrial Automation: Used for motor control in manufacturing and processing equipment to improve automation and efficiency.

2. Conveyor Systems: Suitable for conveyor belts, lifting platforms, and other material handling equipment, providing smooth start, stop, and speed control.

3. Fans & Pumps: In HVAC systems, water treatment, and building facilities, it controls fans and pumps to optimize energy use.

4. Packaging Machinery: Provides precise speed control for packaging machinery, ensuring efficient and stable operation.

5. Robotics & Automation Equipment: Used in various automated robots and arms, enhancing precision and efficiency.

6. Food & Beverage Processing: Controls processes like mixing, packaging, and conveying in food and beverage industries.

7. Mining & Metallurgy: Controls motors in mining and metallurgical processes, ensuring smooth operation in demanding environments.

8. Renewable Energy: Controls motors in wind and solar energy applications, enhancing energy conversion efficiency.

Precautions

1. Correct Installation: Ensure proper wiring and load connections to avoid electrical faults.

2. Stable Power Supply: Ensure the input voltage is stable to prevent damage from voltage fluctuations.

3. Adequate Ventilation: Ensure the installation environment has proper ventilation to prevent overheating.

4. Load Matching: Ensure the drive's power matches the load to prevent overload and extend the lifespan of the equipment.

5. Environmental Conditions: The drive is rated IP20 for indoor use only; external protection is required for harsh environments.

6. Regular Maintenance & Inspection: Periodically check the system’s operational status to ensure optimal performance.

7. Operator Training: Ensure operators are trained on the proper use and maintenance of the drive to minimize downtime.
