1. Product Overview

The ABB ACS355-01E-04A7-2 AC Motor Drive Module is a compact variable frequency drive from the ABB ACS355 series, specifically designed for machinery and OEM applications. It provides precise speed and torque control for three-phase induction motors and permanent magnet synchronous motors, featuring fast commissioning, flexible installation, and comprehensive built-in functions.

2. Technical Specifications

• Model: ACS355-01E-04A7-2

• Product Type: Low-voltage AC motor drive (VFD)

• Series: ABB ACS355

• Input Voltage: 200 – 240 V AC, three-phase

• Input Frequency: 50 / 60 Hz

• Rated Output Current: 4.7 A

• Rated Output Power:

  • 1.1 kW (Heavy Duty)

  • 1.5 kW (Normal Duty)

• Output Frequency Range: 0 – 599 Hz

• Control Methods:

  • Scalar (V/f) control

  • Sensorless vector control

• Motor Types:

  • Three-phase induction motors

  • Permanent magnet synchronous motors (PMSM)

• Overload Capacity:

  • Heavy duty: 150% rated current for 60 s

  • Normal duty: 110% rated current for 60 s

• Degree of Protection: IP20

• Cooling: Forced air cooling

• Braking Function: Built-in brake chopper

• I/O Interfaces:

  • Digital inputs and outputs

  • Analog inputs and outputs

• Communication:

  • Built-in Modbus RTU (RS-485)

  • Optional fieldbus adapters

• Mounting: Wall-mounted or DIN-rail mounting

• Ambient Temperature: –10 °C to +40 °C (without derating)

• Duty Type: Continuous duty (S1)

• Standards: IEC / EN 61800-5-1, CE compliant

3. Advantages and Features

1. Compact and Space-Saving Design
   Ideal for space-constrained control cabinets and OEM machinery.

2. Flexible Control Modes
   Supports both V/f and sensorless vector control for versatile applications.

3. Integrated Brake Chopper
   Simplifies braking solutions and improves dynamic performance.

4. Fast Commissioning
   Application macros and easy parameterization reduce setup time.

5. High Reliability
   Proven ABB drive technology ensures stable and continuous operation.

4. Applications

• Conveyors and material handling systems

• Packaging machinery

• Food and beverage equipment

• Textile and printing machines

• Woodworking and metal processing machinery

• Small hoists and lifting equipment

• OEM machinery and equipment

5. Installation and Usage Notes

1. Verify that the supply voltage matches the drive’s rated input voltage.

2. Install the drive in a well-ventilated environment free from corrosive gases.

3. Enter correct motor nameplate data to ensure optimal control and protection.

4. Select and install braking resistors according to specified ratings and cooling requirements.

5. Ensure proper grounding to minimize electromagnetic interference and ensure safety.
