ABB ACS201-4P1-3-00-10 AC drive

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB ACS201-4P1-3-00-10 is an economical AC variable frequency drive (VFD) designed for controlling the speed and torque of three-phase asynchronous motors. It offers precise speed regulation, energy-efficient operation, and industrial-grade reliability, suitable for pumps, fans, conveyors, and general machinery. The ACS201 series is known for its compact design, easy installation, and user-friendly operation, making it ideal for small to medium industrial automation applications.

2. Technical Specifications

Electrical Specifications

• Model: ACS201-4P1-3-00-10

• Power Rating: 1.1 kW

• Input Voltage: 3AC 380–480 V ±10%

• Output Voltage: 0–380/480 V

• Output Frequency Range: 0–400 Hz

• Rated Current: 2.8 A

• Control Type: V/Hz control

• Communication Interface: Built-in Modbus RTU (RS-485)

• Protection Functions: Overload, overcurrent, overvoltage, undervoltage, short circuit, overheat

Environmental & Installation

• Operating Temperature: –10°C … +50°C

• Storage Temperature: –40°C … +70°C

• Protection Degree: IP20 (panel mount)

• Mounting: Wall or cabinet mount

• Dimensions (HxWxD): 175 mm × 90 mm × 140 mm

• Weight: Approx. 2.3 kg

Additional Features

• Supports PID control and adjustable acceleration/deceleration

• Built-in DC bus braking function (optional)

• Remote monitoring and parameter setting supported

• Energy-saving mode reduces power consumption

• Compliant with CE, UL, and IEC standards

3. Advantages & Key Features

1. Energy-efficient — Precise speed control reduces energy consumption and improves productivity.

2. Easy to use — Simple parameter setting and user-friendly interface for quick commissioning.

3. Industrial-grade reliability — Provides overload, overcurrent, overvoltage, and short-circuit protection.

4. Flexible communication — Built-in Modbus RTU for integration with automation systems.

5. Compact design — Saves installation space and simplifies maintenance.

6. Multi-functional control — Supports PID control, soft start, and energy-saving operation.

4. Application Areas

• Fans, pumps, and compressors

• Conveyors and packaging machinery

• Industrial automation production lines

• HVAC systems

• Small-scale chemical and water treatment plants

• General motor control applications requiring variable frequency operation

5. Precautions

1. Verify input voltage, rated power, and load match the VFD specifications before installation.

2. Install in a dry, well-ventilated environment, avoiding dust, moisture, and corrosive gases.

3. Maintain at least 50 mm clearance around the drive for proper cooling.

4. Wiring and parameter setting must strictly follow the manual to ensure safety.

5. Regularly inspect fans and heat sinks to maintain good cooling performance.

6. Disconnect power before installation or maintenance to ensure personnel safety.
