ABB ACS15003E04A14 AC Inverter Drive

Product Information: ABB ACS150-03E04A-14 AC Inverter Drive

Detailed Specifications:

• Model: ACS150-03E04A-14

• Type: AC Inverter Drive (Single-phase/Three-phase)

• Input Voltage: 200 V to 240 V AC, single-phase

• Rated Power: 0.37 kW (1/2 HP)

• Rated Current: 2.2 A

• Input Frequency: 50/60 Hz

• Output Frequency: 0 to 500 Hz

• Control Method: Vector Control (V/F Control)

• Rated Output Voltage: 200 V to 240 V AC

• Overload Capability: 150% rated current, short-term (1 minute)

• Protection Rating: IP20

• Communication Interface: No built-in communication interface (optional)

• Operating Temperature Range: -10°C to +50°C

• Storage Temperature Range: -20°C to +60°C

• Cooling Method: Forced air cooling (internal fan)

• Dimensions: 132 x 100 x 155 mm

• Weight: 1.2 kg

• Certifications: CE, UL, RoHS, ISO 9001

Product Advantages and Features:

1. Easy Installation and Setup: The ACS150 drive is compact and easy to install, suitable for various small-scale equipment such as fans, pumps, and conveyors. It is simple to configure, making it ideal for beginners and routine use.

2. Wide Frequency Adjustment Range: With output frequency ranging from 0 Hz to 500 Hz, it offers flexible speed control options, ensuring that the equipment can adapt to various operating conditions.

3. Energy Efficiency: By adjusting the motor speed, the ABB ACS150 can significantly reduce energy consumption, minimizing electricity costs during motor start and stop, and reducing overall operating expenses.

4. High Overload Capability: With a 150% overload capacity (for 1 minute), the drive is well-suited for applications where load fluctuations are frequent, providing reliable protection and stable operation.

5. Robust Protection Design: The drive has an IP20 protection rating, making it suitable for general industrial environments, protecting it from dust and other contaminants and ensuring reliable long-term performance.

6. Wide Temperature Range: The drive operates effectively in environments with temperatures ranging from -10°C to +50°C, making it ideal for applications in factories or outdoor settings where temperature variations are common.

7. Internal Cooling: The drive features an internal fan for forced air cooling, ensuring efficient heat dissipation and stable performance under high loads.

8. Safety and Reliability: The product is certified with CE, UL, and other standards, ensuring its quality and safety for use in various industrial control environments.

Applications:

• Small Machinery: Suitable for driving and controlling small equipment such as fans, pumps, and conveyors, especially providing precise speed control in small automation systems.

• HVAC Systems: Used to control fan speeds in air conditioning and ventilation systems, optimizing energy efficiency in HVAC applications.

• Water Treatment Industry: Drives water pumps, aeration equipment, etc., to achieve energy-efficient and stable operation in water treatment systems.

• Home Appliances: Can be used in home appliances such as air conditioners, refrigerators, and washing machines for motor control.

• Automation Production Lines: Used in small automation equipment or production lines for speed regulation and process control, helping to improve production efficiency.

Precautions:

1. Correct Wiring: Ensure that the wiring is in compliance with electrical standards during installation to avoid malfunction due to incorrect connections.

2. Avoid Overload Operation: Although it has a 150% overload capability, avoid running the drive in overload conditions for extended periods to prolong its lifespan.

3. Environmental Suitability: Install the drive in an environment with appropriate temperature and humidity conditions, avoiding exposure to extreme conditions.

4. Regular Maintenance: Periodically check the status of the drive and its fan, keep ventilation openings clean, and ensure that the cooling system is functioning properly.

5. Communication Options: If communication with other devices is needed, consider selecting appropriate communication modules to ensure compatibility between the drive and the system.
