ABB ACS-AP-I Auxiliary Control Panel

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB ACS-AP-I is an Auxiliary Control Panel designed for ABB ACS series drives. It provides extended operation, monitoring, and control functions, allowing operators to start/stop, adjust speed, view fault codes, and configure parameters easily for the drive system.

The ACS-AP-I features a compact and user-friendly design, supporting local and remote operation, and seamlessly integrates with ACS500, ACS550, ACS580, and other ACS series drives. It is widely used in pumps, fans, compressors, and industrial automation drive systems.

2. Main Technical Specifications

• Model: ACS-AP-I

• Type: Auxiliary Control Panel

• Compatible Drives: ABB ACS Series (ACS500, ACS550, ACS580, etc.)

• Operation Functions: Start/Stop, Forward/Reverse, Speed Setting, Mode Selection

• Display: LED or LCD for operation status, fault codes, and parameter information

• Communication Interface: Modbus RTU or fieldbus (model dependent)

• Operating Power: 24 V DC (provided by drive)

• Operating Temperature: -10°C to +50°C

• Protection Class: IP20 / IP54 (panel housing)

• Mounting: Panel or cabinet mount

• Dimensions & Weight: 150×100×50 mm, ~0.7 kg

• Key Lifespan: >100,000 operations

3. Advantages and Features

1. Easy and Intuitive Operation

• Clear layout with straightforward key and display operation.

• Supports start/stop, direction change, speed adjustment, and mode selection.

2. High Compatibility

• Compatible with ABB ACS series drives, supporting local and remote operation.

• System integration via Modbus or fieldbus communication.

3. Safety and Reliability

• Displays overcurrent/overvoltage warnings for quick fault handling.

• High protection rating suitable for industrial environments.

4. Modular Design

• Compact and lightweight for easy panel or cabinet installation.

• Can be combined with other auxiliary modules for extended functionality.

5. High Maintainability

• Keys and display modules can be replaced independently.

• LED/LCD indicators provide clear status and facilitate fault diagnostics.

4. Typical Application Areas

• Industrial drives for pumps, fans, compressors

• HVAC drive control systems

• Industrial automation production line drives

• Water and wastewater treatment systems

• Renewable energy drives and energy-saving control systems

5. Precautions

1. Verify panel model compatibility with the drive before installation.

2. Install in a dry, ventilated environment free from strong electromagnetic interference.

3. Ensure secure cabling for power and communication connections.

4. Avoid prolonged use in high temperature, corrosive, or high-vibration environments.

5. Regularly inspect keys, display, and communication interfaces.

6. In case of alarms or abnormal operation, troubleshoot according to the drive manual.

7. Do not disassemble the panel while powered to avoid electric shock or equipment damage.
