ABB ACF5000 Infrared Radiation Monitoring System

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB ACF5000 is a high-precision infrared radiation monitoring system (IRMS) for non-contact temperature monitoring of high-temperature industrial and power equipment. It utilizes infrared radiation principles to measure temperature, predict potential faults, and ensure safe and stable operation of power systems, industrial machinery, and critical production processes.

2. Technical Specifications

• Model: ACF5000

• Type: Infrared Radiation Monitoring System

• Measurement Principle: Non-contact infrared temperature measurement

• Temperature Range: ‑20 °C to +1000 °C (sensor dependent)

• Accuracy: ±1 % FS or ±1 °C (depending on range)

• Response Time: ≤ 150 ms

• Monitoring Channels: Expandable 4–32 channels (system dependent)

• Output Interfaces: 4–20 mA, RS485, Ethernet/IP, Modbus (optional)

• Alarm Functions: Over-temperature, device fault, communication failure

• Display Interface: Color touch LCD or PC monitoring software

• Mounting: Wall-mounted, rack-mounted, or on-site bracket

• Operating Temperature: ‑20 °C to +60 °C

• Protection Rating: IP54 / IP65 (depending on environment)

• Standards: CE, IEC 61508 (functional safety)

3. Key Advantages & Features

1. Non-Contact Monitoring – Safe and efficient, suitable for high-temperature or hazardous environments.

2. High-Precision Measurement – Detects equipment anomalies accurately.

3. Multi-Channel Expansion – Supports multiple temperature channels for complex systems.

4. Real-Time Alarm & Data Logging – Temperature alarms and historical trend analysis enhance maintenance efficiency.

5. Compatibility & Integration – Supports various industrial communication protocols for PLC, SCADA, or DCS integration.

6. Rugged & Durable – Industrial-grade design resistant to high temperature, dust, and water.

4. Typical Applications

• Temperature monitoring of high-voltage switchgear, transformers, and power equipment

• Industrial furnaces, boilers, and high-temperature machinery

• Power plants, substations, and critical infrastructure

• Petrochemical, metallurgical, steel, and manufacturing high-temperature equipment

• Process automation and energy management systems

5. Installation & Usage Notes

1. Field of View Alignment – Ensure the infrared sensor points to the monitored equipment without obstructions.

2. Power & Wiring – Connect system power and communication interfaces as per manual for stable operation.

3. Environmental Conditions – Avoid strong dust, high humidity, or corrosive exposure to the sensor optics.

4. Regular Calibration & Cleaning – Calibrate sensors and clean optical windows periodically to maintain accuracy.

5. Alarm Settings – Set temperature thresholds based on equipment characteristics for timely alerts.
