ABB 88TK05 Coupling Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• • • • • • • • • • • • • • • • • • • • Product Information & Specifications

                                        • Model: 88TK05

                                        • Part Number: examples include GJR2393200R1210, GJR2393200R1220

                                        • Type: Station‑bus Coupling Module (Coupling a PROCONTROL station to a remote bus)

                                        • Power Supply: 24 V DC ±25%

                                        • Typical Power Consumption: approx. 4 W

                                        • Interfaces:

                                          • One standard interface (SS) for the station bus

                                          • One RS‑485 interface to connect with a remote‑bus coupling module (e.g., 88FT05)

                                          • One potential‑isolated monitoring interface for cabinet announcements (e.g., power‑supply fault, door open)

                                        • Dimensions / Weight: approx. 19.8 cm × 2.0 cm × 26.1 cm; weight approx. 0.5 kg

                                        • Functionality / Compatibility:

                                          • Supports single‑channel or dual‑channel station‑bus coupling modes

                                          • Can be plugged into any slot of a PROCONTROL cabinet (standard cabinets reserve specific slots)

                                          • Intended to handle data exchange within a PROCONTROL station and between the station bus and the remote bus

                                        • Origin: eg. Germany/Sweden (manufactured by ABB)

                                        Advantages & Features

                                        • Centralised Communication Gateway: Acts as the bridge between station‑bus and remote‑bus for reliable data transfer.

                                        • Multi‑Interface Integration: Incorporates station bus, RS‑485 remote bus, monitoring interface in one module facilitating system integration.

                                        • Modular & Replaceable: Plug‑in design allows easier maintenance, module replacement or system expansion.

                                        • High Compatibility: Supports legacy PROCONTROL modules (manufactured after 1987) and integrates with modern station configurations.

                                        • Industrial‑Grade Reliability: Equipped with diagnostics, monitoring capabilities and high reliability for demanding process control applications.

                                        Application Areas

                                        • Large industrial process control systems (e.g., petrochemical, power generation, steel, chemical plants) using PROCONTROL architecture.

                                        • Control cabinets in DCS/PLC systems where station communication and remote bus coupling is required.

                                        • Automation production lines, remote I/O stations, and any system requiring station‑bus and remote‑bus connection.

                                        • Retrofit and spare part scenarios for existing ABB PROCONTROL systems preserving original communication infrastructure.

                                        Precautions



                                        • Verify full model and part number prior to purchase (e.g., GJR2393200R1210 vs R1220) to ensure system compatibility.

                                        • Before installation, power down and observe ESD and correct grounding procedures.

                                        • Confirm cabinet slot availability and compatibility with the station‑bus/remote‑bus wiring architecture.

                                        • For dual‑channel coupling mode, ensure paired module, addressing and switching mechanisms are correct.

                                        • The module’s performance is sensitive to environmental conditions (temperature, humidity, vibration, EMI); ensure appropriate installation environment.

                                        • When used as spare or in legacy systems, inspect module condition, test status, service history for aging or faults.

                                        • When upgrading or changing communication structure, evaluate whether the 88TK05 remains appropriate or if newer modules should be used to ensure long‑term support.
