ABB 5SHY3545L0005 integrated gate commutated thyristor (IGCT) module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB 5SHY3545L0005 Integrated Gate Commutated Thyristor (IGCT) Module Data Sheet

Main Specifications

• Model: 5SHY3545L0005

• Type: Integrated Gate Commutated Thyristor (IGCT) Module

• Power rating: 4500 A / 4500 V

• Rated current: 4500 A

• Rated voltage: 4500 V

• Poles: Single-phase/three-phase (depending on system configuration)

• Operating temperature: -40°C to +125°C

• Packaging: Modular

• Cooling method: Water-cooled or forced air-cooled (application dependent)

• Typical switching frequency: ≤ 200 Hz

• Mounting: Standard mounting bracket with professional IGCT drive interface

Features and Advantages

1. High power capability — Supports high-current, high-voltage industrial applications.

2. Fast turn-off performance — Improves switching efficiency and reduces energy loss.

3. High reliability — Designed for harsh industrial environments.

4. Modular design — Facilitates system integration and maintenance.

5. Low conduction loss — Energy-efficient and reduces cooling requirements.

6. Strong compatibility — Works with ABB high-voltage drives, rectifiers, and power control equipment.

Typical Application Areas

• High-voltage direct current (HVDC) transmission systems

• Power conversion systems: Rectifiers and inverters

• Industrial high-power drive systems

• High-power equipment in metallurgy and chemical industries

• Energy infrastructure and renewable energy systems (e.g., wind and photovoltaic large-scale inverters)

Precautions

1. Installation and operation must be performed by qualified personnel; ensure proper drive interface and cooling system configuration.

2. Avoid use in high humidity or corrosive environments; ensure proper module cooling.

3. Power must be disconnected during maintenance to prevent electric shock and device damage.

4. Observe IGCT triggering current and turn-off time parameters according to ABB manual.

5. Avoid overloading and short-circuit operation to prevent module damage.

The structure and details of the product：
