ABB 5SHX1445H0002 3BHL000387P0101 AC drive
Item NO.:
5SHX1445H0002 3BHL00Payment:
T/TPrice:
$2050Product Origin:
swedenColor:
SEWProduct weight:
0.94KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
The ABB 5SHX1445H0002 / 3BHL000387P0101 AC Drive Module is a high-performance power module widely used in ABB medium and high voltage drive systems and industrial motor control applications.
It adopts IGCT (Integrated Gate-Commutated Thyristor) technology, offering exceptional reliability, high efficiency, and superior dynamic response.
The module converts DC power into controlled AC output, ensuring smooth and precise motor speed regulation.
| Item | Specification |
|---|---|
| Model | 5SHX1445H0002 / 3BHL000387P0101 |
| Type | AC Drive Module |
| Main Technology | IGCT (Integrated Gate-Commutated Thyristor) |
| Rated Voltage | 4500 V |
| Rated Current | 2500 A |
| Operating Voltage Range | 2000 – 4500 V DC |
| Control Type | Vector Control / DTC (Direct Torque Control) compatible |
| Switching Frequency | 0.5 – 2 kHz adjustable |
| Efficiency | ≥ 98% |
| Cooling Method | Forced air cooling / liquid cooling (depending on configuration) |
| Communication Interface | Integrated with ABB control units (e.g., NDCU / NINT series) |
| Protection Functions | Overvoltage, undervoltage, overcurrent, overtemperature, short circuit |
| Insulation Voltage | ≥ 6 kV (module-to-ground and inter-module) |
| Operating Temperature | -10°C to +50°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% – 95%, non-condensing |
| Weight | Approx. 5.5 kg |
| Dimensions (approx.) | 260 × 190 × 60 mm |
| Standards | IEC 61800, EN 50178, CE, UL Certified |
High reliability – Original ABB IGCT technology ensures long lifespan and stability.
High efficiency – Energy conversion efficiency up to 98%, reducing power loss.
Superior control performance – Supports vector and DTC control with fast torque response.
Modular design – Easy integration, installation, and maintenance.
Strong noise immunity – Enhanced electrical isolation and shielding design.
Comprehensive protection – Built-in overvoltage, overcurrent, and thermal protection.
Wide compatibility – Seamless integration with ABB ACS, DCS800, and MVD drive systems.
Medium and high voltage drive systems
Industrial motor speed control and regulation
Metallurgy, mining, cement, power, and petrochemical industries
Pumps, fans, compressors, and rolling mills
ABB ACS / DCS / MVD series industrial drive platforms
Automation and process control systems
Installation and maintenance must be performed by ABB-certified technicians.
Verify model compatibility with system control units before installation.
Ensure proper cooling — use liquid cooling when required.
Avoid exposure to high temperature, humidity, or corrosive gases.
Disconnect power and discharge capacitors before handling.
Install in a dust-proof and vibration-resistant enclosure.
Regularly inspect fans, thermal sensors, and electrical connections.
The structure and details of the product：
Please make an inquiry for more models
