ABB 5SHX1445H0001 (IGCT) module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Overview

ABB 5SHX1445H0001 IGCT Module
The ABB 5SHX1445H0001 is a high-power IGCT (Integrated Gate-Commutated Thyristor) module designed for applications requiring high voltage, high current, and exceptional reliability. It combines the low conduction losses of a thyristor with the fast turn-off capability of a transistor, making it ideal for medium- and high-voltage power electronic systems.

Technical Specifications

• Model: 5SHX1445H0001

• Product Type: IGCT power semiconductor module

• Technology: Integrated Gate-Commutated Thyristor (IGCT)

• Rated Blocking Voltage: Medium- to high-voltage class (system dependent)

• Rated On-State Current: Suitable for high-current industrial applications

• Switching Characteristics:

  • Fast turn-off capability

  • Low switching losses

• Conduction Loss: Low on-state voltage drop for high efficiency

• Package Type: Press-pack power module

• Cooling Method: Suitable for water or high-efficiency air cooling (system dependent)

• Gate Drive: Dedicated IGCT gate drive unit required

• Operating Temperature: Designed for harsh industrial environments

• System Compatibility: ABB medium-voltage power electronics and drive systems

• Standards: IEC standards for power electronics and industrial applications

Advantages and Features

1. Very High Power Handling Capability
   Ideal for medium- and high-voltage, high-power systems.

2. Low Conduction and Switching Losses
   Improves overall system efficiency and reduces energy losses.

3. Fast and Reliable Turn-Off Performance
   Superior dynamic behavior compared to conventional thyristors.

4. Industrial-Grade Reliability
   Based on ABB’s proven power semiconductor technology for continuous operation.

5. Compact Press-Pack Design
   Enables efficient thermal management and robust mechanical integration.

Typical Applications

• Medium-voltage variable speed drives

• High-power motor drive systems

• Power transmission and energy conversion equipment

• Railway traction systems

• Metallurgy, mining, and heavy industrial machinery

• Renewable energy and industrial energy management systems

Installation & Usage Notes

1. The IGCT module must be operated with a dedicated gate drive unit.

2. Proper clamping force is critical to ensure reliable electrical and thermal contact.

3. The cooling system must be designed to meet the thermal requirements of the module.

4. Do not exceed the rated voltage, current, or junction temperature limits.

5. Installation and maintenance should be performed by qualified personnel experienced in high-power electronics.
