ABB 5SHX0845F0001 3BHL000385P0101 IGCT Module – Product Information

1. Product Overview

The ABB 5SHX0845F0001 (Part No. 3BHL000385P0101) is a high-power IGCT (Integrated Gate-Commutated Thyristor) module designed for medium and high-voltage converter systems.
It combines the advantages of GTO and IGBT technologies, offering high current capability, fast switching, and excellent efficiency.
This module is widely used in ABB’s medium-voltage drives, traction systems, and power electronic converters.

2. Technical Specifications

• Model: 5SHX0845F0001

• Part Number: 3BHL000385P0101

• Type: IGCT Power Module

• Package: Press-Pack

• Rated Voltage: 4500 V

• Rated Current: 4000 A

• Repetitive Peak Voltage (VDRM/VRRM): 4500 V

• On-state Voltage (VT): Approx. 2.3 V @ 4000 A

• Gate Drive Voltage: ±20 V

• Gate Current: ≤ 20 A

• Switching Frequency: Up to 1 kHz (depending on cooling)

• Turn-off Time (tq): ≤ 150 μs

• Thermal Resistance (RthJC): ≈ 0.015 K/W

• Operating Temperature: -40 ℃ to +125 ℃

• Cooling Method: Liquid or forced air cooling

• Weight: Approx. 1.3 kg

• Compliance: IEC 60747, UL 1557, RoHS

3. Features and Advantages

1. High voltage and current handling – Supports up to 4.5 kV / 4000 A.

2. Low conduction loss – Ensures high energy efficiency and low heat generation.

3. Fast switching – Enables dynamic and precise control.

4. Rugged press-pack design – Ensures mechanical robustness and superior heat dissipation.

5. High reliability – Designed for long-term industrial operation.

6. Excellent thermal management – Compatible with liquid or air cooling systems.

7. Strong EMC performance – Reliable operation in electrically noisy environments.

4. Application Areas

• Medium-voltage drives (MV Drives)

• HVDC converter valves

• FACTS power converters

• Large motor starters and speed control systems

• Railway traction converters

• Renewable energy converters (wind and solar)

• Industrial furnaces and induction heating systems

5. Precautions

1. Ensure tight thermal contact between the module and heatsink.

2. Use ABB-approved press tools for uniform pressure during mounting.

3. Use recommended ABB gate driver units (e.g., 5SDD series).

4. Do not exceed rated voltage, current, or temperature limits.

5. Store and handle in a dry, vibration-free environment.

6. Regularly inspect electrical contacts and cooling performance.
