ABB 5SDF0260D0001 Power Module

ABB 5SDF0260D0001 Power Module Product Information

Technical Specifications:

• Model: 5SDF0260D0001

• Type: Power Module

• Rated Voltage: DC 1200V

• Rated Current: 260A

• Power Range: Maximum power output of 260A, suitable for high-power applications

• Operating Frequency: 50Hz / 60Hz

• Control Signal: Uses PWM control technology (Pulse Width Modulation)

• Protection Features: Overload, overvoltage, overcurrent, and short circuit protection

• Efficiency: High efficiency, >98%

• Dimensions: Width: 150mm; Height: 180mm; Depth: 90mm

• Installation Type: DIN rail or bolt-mounting

• Operating Temperature: -10°C to +60°C

• Storage Temperature: -25°C to +85°C

• Weight: Approximately 1.5kg

• Protection Class: IP20

• Certifications: CE, UL

Advantages and Features:

• High Power Density: The 5SDF0260D0001 power module provides 260A of current output, meeting the needs of high-power applications.

• High Efficiency: Utilizes advanced PWM control technology with an efficiency of over 98%, reducing energy consumption and improving the system's operational economics.

• Strong Reliability: Features multiple protection mechanisms, including overload, overvoltage, overcurrent, and short-circuit protection, ensuring stable operation of both the device and the system.

• Wide Operating Temperature Range: Designed to operate in environments from -10°C to +60°C, ensuring reliable operation in harsh conditions.

• Easy Integration: Supports both DIN rail and bolt-mounting installation, allowing for quick integration into existing electrical systems.

• Compact Design: The compact design reduces space usage, making it ideal for installations with limited space.

Applications:

• Industrial Automation: Widely used in applications like motor drives, wind power generation, solar inverters, providing efficient power conversion and control.

• Power Systems: Suitable for power conversion and distribution devices, such as efficient UPS systems, charging stations, and data centers.

• Energy Management: Used in energy management systems for energy conversion, supporting large-scale power conversion and storage applications.

• Renewable Energy: Ideal for solar and wind power generation systems, providing stable power output and control.

Precautions:

• Ensure that the power supply voltage and current match the device's specifications to avoid exceeding the rated range during installation.

• Ensure proper ventilation to prevent overheating during installation and operation.

• Regularly check the device’s operating status and ensure that all protection functions are working correctly to prevent damage.

• Install the device in a location free from high humidity, strong vibrations, and corrosive environments to ensure long-term stable operation.

• Avoid subjecting the device to high current surges or sudden short circuits during use, as these can damage the power module and shorten its lifespan.

•
