ABB 58976008 Pulse Encoder

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Overview

The ABB 58976008 is an industrial Pulse Encoder designed for precise measurement of shaft position, speed, and direction. It converts mechanical rotation into standard electrical pulse signals, suitable for motors, drive systems, automated production lines, and robotic control, providing high-precision position feedback for closed-loop control.

Technical Specifications

• Model: 58976008

• Type: Pulse Encoder

• Output Type: Incremental (configurable options)

• Resolution: 1024–4096 pulses per revolution (PPR) selectable

• Supply Voltage: 5–24 V DC (model dependent)

• Output Signal: TTL/HTL square wave, differential or single-ended

• Maximum Speed: 6000 rpm (typical, model dependent)

• Shaft Diameter: 6 mm or 10 mm (customizable)

• Shaft Load: Radial ≤20 N, axial ≤10 N

• Operating Temperature: –20 °C … +80 °C

• Protection Rating: IP65

• Mounting: Flange or shaft coupling

• Dimensions (Diameter × Length): approx. 58 × 58 mm (model dependent)

• Weight: approx. 0.25 kg

• Certifications: IEC 60947-5-2, CE, UL

Advantages and Features

1. High-Precision Position Feedback
   Provides accurate shaft position and speed information for closed-loop control.

2. Wide Speed Response
   Supports high-speed rotation measurement, ensuring real-time motion control.

3. Industrial Environment Resistant
   IP65 rated, dust and moisture resistant, suitable for harsh industrial sites.

4. Multiple Signal Compatibility
   TTL/HTL differential or single-ended output, compatible with PLCs, servo drives, or control systems.

5. Easy Installation
   Flange or shaft coupling installation for easy replacement and maintenance.

6. High Reliability
   Optical or magnetic sensor design ensures long-term stable operation.

Typical Applications

• Motor and drive system speed/position feedback

• Automated production lines and robotic control

• Industrial servo systems and closed-loop motion control

• Packaging, textile, and printing machinery

• Lifts, doors, and motion control equipment

Precautions

1. Verify shaft diameter and interface match the equipment before installation.

2. Ensure proper shielding of signal wires to avoid electromagnetic interference.

3. Operate within –20 °C to +80 °C to prevent overheating damage.

4. Avoid exceeding radial and axial shaft load limits.

5. Periodically check encoder connections and signal output to ensure accuracy and reliability.
