ABB 57310256-K DSBC 111 Bus Termination Module

1. Product Description & Technical Specifications

• Model: 57310256-K

• Module Name: DSBC 111 Bus Termination Module

• Supported Systems: ABB Advant, Master, S100 bus systems

• Main Function: Provides bus termination, impedance matching, signal conditioning, and communication stabilization

• Termination Resistor: Built-in standard impedance resistor

• Installation: Rack-mounted insertion module

• Power Supply: Powered through backplane

• Interface Type: ABB system-specific communication interface

• Operating Temperature: -25°C to +70°C

• Humidity: 5%–95% (non-condensing)

• Dimensions: Approx. 100 × 25 × 80 mm

• Weight: Approx. 0.15 kg

The DSBC 111 is an enhanced version of the DSBC 110, offering improved stability and better noise immunity.

2. Advantages & Key Features

1. High-precision bus termination
   Ensures signal integrity and reduces reflections or distortions on the bus line.

2. Improved noise resistance
   More robust for long-distance communication and harsh industrial environments.

3. Enhanced communication stability
   Reduces errors, dropouts, and unstable communication conditions.

4. Passive and maintenance-free
   No external power or configuration needed.

5. Excellent compatibility
   Works seamlessly with Advant, Master, and older S100 system buses.

6. Easy installation
   Compact, plug-and-play design.

3. Typical Applications

• ABB Advant / Master control systems

• Industrial bus termination and communication networks

• Distributed control systems (DCS)

• Petrochemical, oil & gas, chemical automation

• Power plants, metallurgy, cement industry automation

• Industrial communication line termination

• Legacy ABB system maintenance and replacement

4. Precautions

1. Install only at the end of the bus line to ensure proper impedance matching.

2. Always power off the system before inserting or removing the module.

3. Do not use in the middle of a bus chain.

4. Keep contacts clean to maintain communication quality.

5. Avoid humid, corrosive environments; use inside a protected cabinet.

6. Ensure the rack slot matches the DSBC 111 specification.
