ABB 57120001-DE DSAI151 Analog Input Board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB DSAI 151 (part number 57120001-DE) is an analog input board designed for industrial control systems. It is tailored for high-precision temperature measurement, particularly using four-wire Pt100 resistance sensors. It enables collection of multiple temperature signals into the control system for process monitoring and closed-loop control.

2. Technical Specifications

• Model: DSAI 151

• Part Number: 57120001-DE

• Channels: 14 analog inputs (Pt100, 4-wire)

• Input Type: Pt100 resistance thermometer (4-wire)

• Resolution / Accuracy: ~ 0.1 °C for Pt100 inputs

• Dimensions: Depth ~234 mm; Height ~11.7 mm; Width ~216 mm

• Weight: ~0.5 kg

• Mounting: Plug-in board for I/O rack / control cabinet

• Compatible Systems: ABB I/O architecture (e.g., S100 I/O)

3. Advantages & Features

1. High-Precision Temperature Acquisition

   • Supports 4-wire Pt100 connections to minimize lead resistance error, delivering more accurate temperature readings.

2. Multi-Channel Capability

   • 14 independent input channels allow centralized data collection from multiple temperature sensors, reducing the need for multiple modules.

3. Modular Design

   • Plug-in board form factor enables easy installation, removal, and maintenance.

4. Industrial-Grade Reliability

   • Built for harsh industrial environments, with strong immunity to electrical interference and long-term stability.

5. Strong Compatibility

   • Seamless integration with ABB control systems and I/O racks; suitable for use as a replacement or expansion module.

4. Application Areas

• Process Industries: Chemical, petrochemical, pharmaceutical sectors for precise temperature monitoring and control.

• Energy / Power: Boiler systems, steam circuits, thermal power plants requiring multi-point temperature measurement.

• Manufacturing: Heat treatment lines, temperature-sensitive production processes.

• Automation Systems: DCS / SCADA systems needing analog temperature inputs.

• R&D & Testing: Laboratory test benches for multi-point Pt100 temperature measurement.

5. Precautions & Recommendations

1. Wiring Considerations

   • Use 4-wire connections for Pt100 sensors to minimize measurement error due to lead resistance.

   • Use shielded, properly grounded wiring to reduce electrical noise.

2. ESD Protection

   • Power down before inserting or removing the board.

   • Use anti-static wrist strap when handling the module to avoid electrostatic damage.

3. Thermal & Installation Environment

   • Install the board in a well-ventilated control cabinet to ensure adequate cooling.

   • Avoid exposing the board to extreme temperature or moisture.

4. Calibration & Maintenance

   • Periodically calibrate both the Pt100 sensors and the module’s input for accurate readings.

   • Inspect channel connections for corrosion or looseness, and maintain as needed.

5. Compatibility Check

   • Confirm that the control system / I/O rack supports the DSAI 151 module.

   • Ensure module part number and hardware revision match the system requirements when replacing.
