ABB 560SLI02 1KGT009100R0001 PCB printed circuit board

ABB 560SLI02 / 1KGT009100R0001

Printed Circuit Board (PCB)

Product Overview

The ABB 560SLI02 (part number 1KGT009100R0001) is an industrial printed circuit board used in ABB RTU560 or related control and communication systems.
This PCB performs digital logic and signal processing functions within ABB’s remote terminal units or process control modules.
It is designed for reliable operation in demanding industrial environments and is typically used as a logic interface or signal board within automation equipment.

Technical Specifications

Note: Some specifications are derived from multiple supplier sources and may vary slightly between revisions.

Key Features and Advantages

1. Fully Compatible with ABB RTU / Control Systems
   Designed specifically for ABB RTU560 or related automation modules, ensuring electrical and mechanical compatibility.

2. Industrial-Grade Design
   Built with durable PCB materials and controlled impedance layout suitable for harsh industrial environments.

3. Version Flexibility
   Multiple revisions (A through I) supported, allowing compatibility with both older and newer system generations.

4. Compact and Lightweight
   Small footprint (160 × 100 mm, ~280 g) for easy integration and maintenance.

5. Reliable Digital Logic Performance
   Handles internal logic processing, signal transmission, or interface functions within automation or communication subsystems.

Application Areas

• ABB RTU 560 systems (logic and interface modules)

• Industrial automation and process control systems

• Communication interface modules and signal converters

• Control cabinets and electrical panels in power plants or process industries

• Replacement or maintenance spares for ABB industrial control units

Precautions and Handling Notes

1. Check Compatibility
   Always verify compatibility with your host system, backplane, and interface connectors before installation. Revision mismatches may cause malfunctions.

2. Verify Power Supply
   Confirm the correct supply voltage and logic-level requirements. The typical logic voltage is ~1.2 V DC, but actual operating values depend on the system configuration.

3. Electrostatic Discharge (ESD) Protection
   Handle the PCB only with proper anti-static precautions such as grounded wrist straps and ESD-safe work surfaces.

4. Environmental Conditions
   Operate only within rated temperature and humidity limits. Avoid excessive heat, moisture, vibration, or corrosive atmospheres.

5. Inspect Before Use
   When using refurbished or used boards, inspect for corrosion, cracked solder joints, aged capacitors, or mechanical wear before installation.

6. Secure Mounting
   Ensure the PCB is properly seated and mechanically secured in its slot to prevent vibration-related failures or connector loosening.

7. Power Quality and Surge Protection
   Avoid voltage surges, spikes, or supply dips that could damage logic circuits or compromise reliability.

8. Storage Guidelines
   Store spare boards in a clean, dry, static-free environment. For long-term storage, periodically check insulation and connector cleanliness before reuse.

9. Use Official Documentation
   Always refer to ABB’s technical manuals, circuit diagrams, or version notes for accurate wiring, pinout, and installation instructions.

The structure and details of the product：
